Claas TARGO K70 - Assembly - Forward Clutch

TRANSMISSION 3.93
Figure 235
Remove retainer ring retainer.
Figure 236
Remove disc springs.
Figure 237
Remove clutch piston wear plate.
Figure 238
Remove clutch piston.
Figure 240
Install inner and outer clutch piston sealing rings.
Refer to Figure 93 and size inner ring. Install clutch
piston in clutch drum. Make sure sealing rings are
not damaged.
Figure 239
Make sure clutch piston bleed orifice is clean and
free from foreign material.
Assembly - forward clutch
