Clarion APA4320 Service Manual

R118
R119
R120
R121
R122
R123
R124
R125
R126
R127
R128
R129
R130
R131
R132
R133
R134
R136
R137
R138
R139
R140
R141
R142
R143
R144
R145
R146
R147
R148
R149
R150
R151
R152
R153
R154
R155
R156
R157
R158
R159
R160
R161
R162
R163
R164
R165
R166
R168
R167
R169
R170
R171
R172
R173
653-0432-27
653-0432-31
653-0432-23
653-0432-34
653-0432-23
653-0432-31
653-0432-11
653-0432-29
653-0432-25
653-0432-07
653-0432-28
653-0432-27
653-0432-31
653-0432-32
653-0432-31
653-0432-16
653-0432-16
653-0432-07
653-0432-05
653-0432-37
653-0432-14
653-0432-14
653-0432-13
653-0432-34
653-0432-12
653-0432-12
653-0432-06
653-0432-34
653-0432-07
653-0432-13
653-0432-10
653-0432-15
653-0432-07
653-0432-06
653-0432-18
653-0432-37
653-0432-42
653-0432-18
653-0432-39
653-0432-18
653-0432-13
653-0432-06
653-0432-18
653-0432-39
653-0432-18
653-0432-13
653-0432-06
653-0432-02
653-0432-41
653-0432-38
653-0432-36
653-0432-45
653-0437-02
653-0432-12
653-0432-12
01-53910-43
01-54720-63
01-53120-22
01-55001-43
01-53120-22
01-54720-63
01-51538-63
01-54710-43
01-53340-63
01-51030-63
01-54340-63
01-53910-43
01-54720-63
01-54730-63
01-54720-63
01-52130-63
01-52130-63
01-51030-63
01-51010-63
01-55910-63
01-52030-63
01-52030-63
01-52020-63
01-55001-43
01-51830-63
01-51830-63
01-51020-63
01-55001-43
01-51030-63
01-52020-63
01-51420-63
01-52120-63
01-51030-63
01-51020-63
01-52206-63
01-55910-63
01-58220-63
01-52206-63
01-56800-63
01-52206-63
01-52020-63
01-51020-63
01-52206-63
01-56800-63
01-52206-63
01-52020-63
01-51020-63
01-12750-63
01-58200-63
01-56320-63
01-55618-63
01-59320-63
01-51411-63
01-51830-63
01-51830-63
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
392 ohm 1/4W
4.75 K 1/8W
3.16 K 1/2W
5.1 ohm 1/4W
3.16 K 1/2W
4.75 K 1/8W
15.8 K 1/8W
475 ohm 1/4W
332 K 1/8W
10 K 1/8W
432 K 1/8W
392 ohm 1/4W
4.75 K 1/8W
47.5 K 1/8W
4.75 K 1/8W
21 K 1/8W
21 K 1/8W
10 K 1/8W
100 ohm 1/8W
590 ohm 1/8W
20 K 1/8W
20 K 1/8W
2 K 1/8W
5.1 ohm 1/4W
18.2 K 1/8W
18.2 K 1/8W
1 K 1/8W
5.1 ohm 1/4W
10 K 1/8W
2 K 1/8W
1.43 K 1/8W
2.15 K 1/8W
10 K 1/8W
1 K 1/8W
22.1 ohm 1/8W
590 ohm 1/8W
8.25 K 1/8W
22.1 ohm 1/8W
681 ohm 1/8W
22.1 ohm 1/8W
2 K 1/8W
1 K 1/8W
22.1 ohm 1/8W
681 ohm 1/8W
22.1 ohm 1/8W
2 K 1/8W
1 K 1/8W
2.7 M 1/8W
82.5 ohm 1/8W
6.34 K 1/8W
56.2 ohm 1/8W
9.31 K 1/8W
143 ohm 1/8W
18.2 K 1/8W
18.2 K 1/8W
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
-11-
APA4320

Clarion APA4320 Specifications

Audio Output

rated_output_4_channel_mode	80 W x 4
rated_output_3_channel_mode	80 W x 2 + 230 W x 1
rated_output_2_channel_mode	230 W x 2
maximum_power	160 W x 4
frequency_response	10 Hz ~ 50 kHz (+/- 1.0 dB)
harmonic_distortion	0.025% (1 kHz, 10 W, 4Ω)
s_n_rate	100 dB

Power Specifications

applicable_speaker_impedance	4Ω (2Ω-8Ω)
input_sensitivity	200 mV ~ 6, 000 mV
power_source_voltage	14.4 V
power_consumption	37 A (with 80 W x 4 rated output)
power_consumption_no_input	1.6 A (amplifier ON, no input)

Weight and Dimensions

external_dimensions	165(W) x 56(H) x 409(D) mm
weight	3.9 kg
