Clarion APA4320 Service Manual

REF. NO
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
C12
C13
C14
C15
C16
C17
C18
C19
C20
J1
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R12
R13
R14
R15
R16
R17
R18
R19
R20
R21
R22
R23
R24
R25
R26
R27
R28
R29
R30
R31
PART NO
653-0432-62
653-0432-61
653-0432-62
653-0432-61
653-0432-62
653-0432-61
653-0432-62
653-0432-61
653-0432-55
653-0432-55
653-0432-66
653-0432-66
653-0432-66
653-0432-66
653-0432-62
653-0432-62
653-0432-62
653-0432-62
653-0432-55
653-0432-55
653-0437-09
653-0432-13
653-0432-13
653-0432-13
653-0432-13
653-0432-10
653-0432-26
653-0432-13
653-0432-13
653-0432-13
653-0432-13
653-0432-10
653-0432-26
653-0432-31
653-0432-31
653-0432-31
653-0432-31
653-0432-31
653-0432-31
653-0432-31
653-0432-31
653-0432-13
653-0432-13
653-0432-13
653-0432-13
653-0432-13
653-0432-13
653-0432-10
653-0432-10
653-0432-26
653-0432-26
653-0432-13
MANUFACTURE NO
03-25630-04
03-25620-04
03-25630-04
03-25620-04
03-25630-04
03-25620-04
03-25630-04
03-25620-04
03-21040-04
03-21040-04
04-20680-02
04-20680-02
04-20680-02
04-20680-02
03-25630-04
03-25630-04
03-25630-04
03-25630-04
03-21040-04
03-21040-04
32-00656-00
01-52020-63
01-52020-63
01-52020-63
01-52020-63
01-51420-63
01-53420-63
01-52020-63
01-52020-63
01-52020-63
01-52020-63
01-51420-63
01-53420-63
01-54720-63
01-54720-63
01-54720-63
01-54720-63
01-54720-63
01-54720-63
01-54720-63
01-54720-63
01-52020-63
01-52020-63
01-52020-63
01-52020-63
01-52020-63
01-52020-63
01-51420-63
01-51420-63
01-53420-63
01-53420-63
01-52020-63
DESCREPTION
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
CERAMIC
CERAMIC
CERAMIC
CERAMIC
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
POLY CAP
TERMINAL
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
RESISTOR 1%
SPECTIFICATION
563J
562J
563J
562J
563J
562J
563J
562J
104J
104J
68P -NPO- 50V
68P -NPO- 50V
68P -NPO- 50V
68P -NPO- 50V
563J
563J
563J
563J
104J
104J
SLL-KOR-4P*2
2 K 1/8W
2 K 1/8W
2 K 1/8W
2 K 1/8W
1.43 K 1/8W
3.48 K 1/8W
2 K 1/8W
2 K 1/8W
2 K 1/8W
2 K 1/8W
1.43 K 1/8W
3.48 K 1/8W
4.75 K 1/8W
4.75 K 1/8W
4.75 K 1/8W
4.75 K 1/8W
4.75 K 1/8W
4.75 K 1/8W
4.75 K 1/8W
4.75 K 1/8W
2 K 1/8W
2 K 1/8W
2 K 1/8W
2 K 1/8W
2 K 1/8W
2 K 1/8W
1.43 K 1/8W
1.43 K 1/8W
3.48 K 1/8W
3.48 K 1/8W
2 K 1/8W
Q'TY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
CROSS-OVER
-14-
APA4320

Clarion APA4320 Specifications

Audio Output

rated_output_4_channel_mode	80 W x 4
rated_output_3_channel_mode	80 W x 2 + 230 W x 1
rated_output_2_channel_mode	230 W x 2
maximum_power	160 W x 4
frequency_response	10 Hz ~ 50 kHz (+/- 1.0 dB)
harmonic_distortion	0.025% (1 kHz, 10 W, 4Ω)
s_n_rate	100 dB

Power Specifications

applicable_speaker_impedance	4Ω (2Ω-8Ω)
input_sensitivity	200 mV ~ 6, 000 mV
power_source_voltage	14.4 V
power_consumption	37 A (with 80 W x 4 rated output)
power_consumption_no_input	1.6 A (amplifier ON, no input)

Weight and Dimensions

external_dimensions	165(W) x 56(H) x 409(D) mm
weight	3.9 kg
