CONNECTIONS FOR POWER AND SPEAKERS
The rear panel of Clarion’s amplifiers contain power and speaker connections as
shown below.
1. Left Front Speaker Output
2. Right Front Speaker Output
3. Left Speaker Output
4. Right Speaker Output
5. Remote Turn-On Input
6. Ground Input
7. Battery + 12V Input
8. Fuse
9. Left Rear Speaker Output
10. Right Rear Speaker Output
APX640.2
25x2
AMP MAX
L
R
+
+
MIN
MIN
MIN
2
4
2
Figure 4-1 APX320.2 Connections for Power and Speakers
3
APX320.2
30 AMP MAX
L
R
+
+
MIN
MIN
MIN
2
4
2
Figure 4-2 APX640.2 Connections for Power and Speakers
8
5
6
7
4
8
5
6 7
3
4
Owner’s Manual
CONNECTIONS
9
