Clarion CZ209 Service Manual

-11-
CZ209/CZ209A
Switch PWB(B2) section
REF No. PART No. DESCRIPTION REF No. P ART No. DESCRIPTION REF No. PART No. DESCRIPTION
C701 043-1841-90 0.047uF J702 075-9021-50 5P R722 119-5621-15 1/10W 5.6k ohm
C702 043-1841-90 0.047uF LCD701 379-1426-41
INDICATOR(LCD)
R724 119-2221-15 1/10W 2.2k ohm
C703 043-1841-90 0.047uF P701 076-0502-55 5P R725 119-1021-15 1/10W 1k ohm
C704 043-1800-90 1000pF Q713 125-2027-92 DTC124EUA R726 119-5621-15 1/10W 5.6k ohm
C705 042-0423-97 16V 10uF Q713 125-2041-93 RT1N241M S701 013-6312-50 SWITCH
C706 042-0423-97 16V 10uF Q714 125-2027-92 DTC124EUA S702 013-6312-50 SWITCH
C707 043-1841-90 0.047uF Q714 125-2041-93 RT1N241M S703 013-6312-50 SWITCH
D702 001-4907-90 PG05GBUSU R701 119-3311-15 1/10W 330 ohm S704 013-6312-50 SWITCH
D705 001-4301-29 HZU5.1B2 R702 119-3931-15 1/10W 39k ohm S705 013-6312-50 SWITCH
D706 001-4301-29 HZU5.1B2 R703 119-1041-15 1/10W 100k ohm S706 013-6312-50 SWITCH
D707 001-4907-90 PG05GBUSU R704 119-3921-15 1/10W 3.9k ohm S707 013-6312-50 SWITCH
D708 001-4907-90 PG05GBUSU R705 119-2221-15 1/10W 2.2k ohm S709 013-6312-50 SWITCH
D711 001-7097-91 DIODE R706 119-1021-15 1/10W 1k ohm S710 013-6312-50 SWITCH
D712 001-7097-91 DIODE R707 119-1021-15 1/10W 1k ohm S711 013-6312-50 SWITCH
D713 001-7097-91 DIODE R708 119-1011-15 1/10W 100 ohm S713 013-6312-50 SWITCH
D714 001-7097-91 DIODE R709 119-4721-15 1/10W 4.7k ohm S714 013-6312-50 SWITCH
D715 001-7114-91 DIODE R713 119-6811-15 1/10W 680 ohm S715 013-6312-50 SWITCH
D716 001-7114-91 DIODE R714 119-6811-15 1/10W 680 ohm S716 013-6312-50 SWITCH
D717 001-4301-29 HZU5.1B2 R715 119-1811-15 1/10W 180 ohm S717 013-6312-50 SWITCH
D718 001-4301-41 HZU7.5B2 R716 119-1811-15 1/10W 180 ohm S718 016-9901-02 VR W/SHAFT
D720 001-4301-51 HZU10B3 R717 119-1811-15 1/10W 180 ohm PWB 039-3388-00 PWB(WITHOUT
IC701 051-6095-00 LC75857 R718 119-1811-15 1/10W 180 ohm COMPONENT)
IR701 060-4021-00 GPIUX51 R719 119-6811-15 1/10W 680 ohm
J701 076-0615-50 12P R720 119-6811-15 1/10W 680 ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R637 033-1031-15 1/10W 10k ohm R811 119-1531-15 1/10W 15k ohm R857 119-1021-15 1/10W 1k ohm
R638 119-1031-15 1/10W 10k ohm R812 119-2231-15 1/10W 22k ohm R858 033-1031-15 1/10W 10k ohm
R639 033-1031-15 1/10W 10k ohm R813 119-2231-15 1/10W 22k ohm R859 033-1031-15 1/10W 10k ohm
R640 033-3921-15 1/10W 3.9k ohm R815 033-6811-15 1/10W 680 ohm R860 033-1031-15 1/10W 10k ohm
R641 033-1031-15 1/10W 10k ohm R817 033-6811-15 1/10W 680 ohm R861 033-1031-15 1/10W 10k ohm
R643 033-1531-15 1/10W 15k ohm R818 033-6831-15 1/10W 68k ohm R862 119-6831-15 1/10W 68k ohm
R644 033-1531-15 1/10W 15k ohm R820 119-1011-15 1/10W 100 ohm R863 119-2231-15 1/10W 22k ohm
R645 033-3301-15 1/10W 33 ohm R821 119-1011-15 1/10W 100 ohm R865 119-3351-15 1/10W 3.3M ohm
R646 033-3301-15 1/10W 33 ohm R825 119-3921-15 1/10W 3.9k ohm R866 033-1031-15 1/10W 10k ohm
R647 033-1011-15 1/10W 100 ohm R826 119-3921-15 1/10W 3.9k ohm R867 119-1031-15 1/10W 10k ohm
R648 033-1011-15 1/10W 100 ohm R827 119-3921-15 1/10W 3.9k ohm R870 032-0140-54
1/10W 22k ohm F
R649 033-1011-15 1/10W 100 ohm R828 033-2731-15 1/10W 27k ohm R871 032-0140-50 1/10W 10k ohm F
R650 033-1011-15 1/10W 100 ohm R829 033-1021-15 1/10W 1k ohm R872 119-6221-15 1/10W 6.2k ohm
R652 119-0000-05 1/10W 0 ohm JW R830 033-1011-15 1/10W 100 ohm R873 119-1031-15 1/10W 10k ohm
R653 119-0000-05 1/10W 0 ohm JW R831 033-2221-15 1/10W 2.2k ohm R874 119-6221-15 1/10W 6.2k ohm
R654 033-2221-15 1/10W 2.2k ohm R832 033-2221-15 1/10W 2.2k ohm R875 119-6821-15 1/10W 6.8k ohm
R655 119-0000-05 1/10W 0 ohm JW R833 033-2221-15 1/10W 2.2k ohm R876 033-3331-15 1/10W 33k ohm
R656 119-0000-05 1/10W 0 ohm JW R834 119-2201-15 1/10W 22 ohm R877 033-3331-15 1/10W 33k ohm
R657 119-0000-05 1/10W 0 ohm JW R835 033-3321-15 1/10W 3.3k ohm R907 119-1031-15 1/10W 10k ohm
R658 119-0000-05 1/10W 0 ohm JW R836 033-1511-15 1/10W 150 ohm R911 032-0140-88
1/10W100 k ohm F
R659 119-0000-05 1/10W 0 ohm JW R837 033-2231-15 1/10W 22k ohm R936 033-1021-15 1/10W 1k ohm
R660 119-0000-05 1/10W 0 ohm JW R839 119-4701-15 1/10W 47 ohm S501 013-6100-00 SWITCH
R661 119-0000-05 1/10W 0 ohm JW R840 119-3301-15 1/10W 33 ohm SUP202 060-0122-20 DSP-141N-S00B
R663 119-0000-05 1/10W 0 ohm JW R841 119-1511-15 1/10W 150 ohm T101 009-9006-60 CHOKE 0.23mH
R801 033-3311-15 1/10W 330 ohm R842 119-1511-15 1/10W 150 ohm T101 009-9006-70 CHOKE 0.23mH
R802 119-1031-15 1/10W 10k ohm R845 033-0000-05 1/10W 0 ohm X501 061-1056-00 32.768kHz
R804 033-4711-15 1/10W 470 ohm R846 033-0000-05 1/10W 0 ohm X502 061-3562-90 13.5MHz
R805 033-4721-15 1/10W 4.7k ohm R847 033-0000-05 1/10W 0 ohm X601 061-1081-50 12MHz
R806 033-4721-15 1/10W 4.7k ohm R848 033-0000-05 1/10W 0 ohm X801 060-1535-90 16.934MHz
R807 116-3391-15 1/4W 3.3 ohm R853 119-2721-15 1/10W 2.7k ohm PWB 039-3386-00 PWB(WITHOUT
R808 119-0000-05 1/10W 0 ohm JW R854 119-1021-15 1/10W 1k ohm COMPONENT)
R809 119-0000-05 1/10W 0 ohm JW R855 119-1021-15 1/10W 1k ohm
R810 119-2231-15 1/10W 22k ohm R856 119-1021-15 1/10W 1k ohm
