Clarion CZ209 Service Manual

-10-
CZ209/CZ209A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D506 001-1323-90 L1SS355T1G Q411 125-4012-90 KTD1304 R446 033-1031-15 1/10W 10k ohm
D507 001-1323-90 L1SS355T1G Q413 125-4012-90 KTD1304 R448 119-2231-15 1/10W 22k ohm
D508 001-1323-90 L1SS355T1G Q414 125-4012-90 KTD1304 R449 119-2231-15 1/10W 22k ohm
D601 001-4301-41 HZU 7.5B2 Q500 125-4024-90 3DG3875 R452 119-3311-15 1/10W 330 ohm
D602 060-8078-00 EZAEG3A50AV Q501 125-3014-90 ISA1602AM1 R453 119-3311-15 1/10W 330 ohm
D603 060-8078-00 EZAEG3A50AV Q501 190-1576-00 2SA1576A T106 R454 119-2231-15 1/10W 22k ohm
D604 001-1323-90 L1SS355T1G Q502 125-3014-90 ISA1602AM1 R455 119-3311-15 1/10W 330 ohm
D801 001-1323-90 L1SS355T1G Q502 190-1576-00 2SA1576A T106 R456 119-3311-15 1/10W 330 ohm
D802 001-0644-90 MA113 Q503 125-2027-91 DTC114EUA R457 119-2231-15 1/10W 22k ohm
IC105 051-3349-00 HA13166E Q503 125-2041-92 RT1N141M R458 033-1021-15 1/10W 1k ohm
IC302 051-5028-90 TDA7409DTR Q504 125-2027-92
DTC124EUA-T106
R459 033-1021-15 1/10W 1k ohm
IC305 051-3060-90 AZ4558C Q504 125-2041-93 RT1N241M R500 116-4721-15 1/4W 4.7k ohm
IC402 051-2060-00 LA47201-N-E Q505 125-0034-97 RT1P136M-T111 R501 119-4731-15 1/10W 47k ohm
IC501 052-3996-00 LC8783G0PA- Q515 125-2027-92
DTC124EUA-T106
R502 033-4721-15 1/10W 4.7k ohm
5AE8-E Q515 125-2041-93 RT1N241M R503 033-4731-15 1/10W 47k ohm
IC502 051-5443-38 S80850CNMC Q516 125-0034-97 RT1P136M-T111 R504 033-4721-15 1/10W 4.7k ohm
IC503 051-5437-58 R3111N211A Q801 190-2060-00 2SA2060 R505 033-1031-15 1/10W 10k ohm
IC600 052-3995-90 LC87F1HC8A- Q802 101-0941-00
2SB941
R506 033-1041-15 1/10W 100k ohm
F5AF1-E Q901 125-0021-91
DTA114EUA
R507 033-6831-15 1/10W 68k ohm
IC601 051-6926-90 BD2051AFJ-TR Q902 125-2027-92
DTC124EUA-T106
R508 119-1021-15 1/10W 1k ohm
IC801 051-6743-00 LC786920E Q902 125-2041-93
RT1N241M
R509 119-1031-15 1/10W 10k ohm
IC802 051-6096-90 LA6242H R108 033-1031-15
1/10W 10k ohm
R510 119-1021-15 1/10W 1k ohm
IC901 051-6928-90 341S2094 R154 116-1521-15
1/4W 1.5k ohm
R511 119-0000-05 1/10W 0 ohm JW
J401 074-1214-50 16P R156 119-1241-15
1/10W 120k ohm
R512 119-1021-15 1/10W 1k ohm
J501 074-1217-50 12P R159 116-1221-15
1/4W 1.2k ohm
R513 033-4731-15 1/10W 47k ohm
J502 075-0393-50 JACK R169 119-2211-15 1/10W 220 ohm R514 033-4731-15 1/10W 47k ohm
J801 074-2246-67 17P R200 119-1031-15 1/10W 10k ohm R515 119-1841-15 1/10W 180k ohm
L201 010-2003-04 30uH(Variable) R201 119-5631-15 1/10W 56k ohm R516 033-4731-15 1/10W 47k ohm
L202 010-3105-67 1.5k ohm/100kHz R207 119-0000-05 1/10W 0 ohm JW R517 033-2221-15 1/10W 2.2k ohm
L203 010-3105-67 1.5k ohm/100kHz R209 119-2711-15 1/10W 270 ohm R518 033-1031-15 1/10W 10k ohm
L206 010-6009-57 0.56uH R212 119-0000-05 1/10W 0 ohm JW R519 033-3921-15 1/10W 3.9k ohm
L301 010-6009-84 100uH J R225 033-1031-15 1/10W 10k ohm R521 033-5641-15 1/10W 560k ohm
L302 119-0000-05 1/10W 0 ohm JW R230 033-1021-15 1/10W 1k ohm R522 119-1021-15 1/10W 1k ohm
L303 119-0000-05 1/10W 0 ohm JW R233 119-4741-15 1/10W 470k ohm R526 033-1031-15 1/10W 10k ohm
L304 119-0000-05 1/10W 0 ohm JW R236 119-3311-15 1/10W 330 ohm R527 033-1031-15 1/10W 10k ohm
L305 119-0000-05 1/10W 0 ohm JW R238 033-2221-15 1/10W 2.2k ohm R528 033-5621-15 1/10W 5.6k ohm
L501 010-3112-90 1k ohm/100MHz R239 033-2221-15 1/10W 2.2k ohm R529 119-4721-15 1/10W 4.7k ohm
L502 010-3123-90 2.2uH R313 033-2711-15 1/10W 270 ohm R530 033-1031-15 1/10W 10k ohm
L503 010-3123-90 2.2uH R314 033-2711-15 1/10W 270 ohm R531 033-4721-15 1/10W 4.7k ohm
L504 010-3123-90 2.2uH R315 033-2711-15 1/10W 270 ohm R532 119-4721-15 1/10W 4.7k ohm
L601 010-6009-81 56uH J R316 033-2711-15 1/10W 270 ohm R533 033-1041-15 1/10W 100k ohm
L801 010-6009-76 22uH J R317 119-3311-15 1/10W 330 ohm R534 033-1031-15 1/10W 10k ohm
L802 010-6009-76 22uH J R325 032-0140-89
1/10W 47k ohm F R535 033-4731-15 1/10W 47k ohm
Q119 125-4026-00 3DA2026 R326 032-0140-89
1/10W 47k ohm F R536 033-2231-15 1/10W 22k ohm
Q123 125-9026-90 IMF29 R328 032-0140-89
1/10W 47k ohm F R537 033-1041-15 1/10W 100k ohm
Q201 125-0025-93 RN2303 R329 032-0140-89
1/10W 47k ohm F R538 119-4711-15 1/10W 470 ohm
Q201 125-0034-93 RT1P241M R332 032-0140-89
1/10W 47k ohm F R539 119-4711-15 1/10W 470 ohm
Q202 125-0025-93 RN2303 R333 032-0140-89
1/10W 47k ohm F R540 119-0000-05 1/10W 0 ohm JW
Q202 125-0034-93 RT1P241M R334 032-0140-89
1/10W 47k ohm F R541 119-1021-15 1/10W 1k ohm
Q203 125-2027-92
DTC124EUA-T106
R335 032-0140-89 1/10W 47k ohm F R542 119-1021-15 1/10W 1k ohm
Q203 125-2041-93 RT1N241M R344 119-1021-15 1/10W 1k ohm R543 033-4721-15 1/10W 4.7k ohm
Q206 125-2027-92
DTC124EUA-T106
R346 119-1041-15 1/10W 100k ohm R544 119-1021-15 1/10W 1k ohm
Q206 125-2041-93 RT1N241M R347 119-1041-15 1/10W 100k ohm R546 119-0000-05 1/10W 0 ohm JW
Q208 125-4011-90 KTD863 R408 033-8221-15 1/10W 8.2k ohm (PE-3157K-A/B)
Q211 192-4116-51 2SC4116 G,L R409 119-1021-15 1/10W 1k ohm R547 119-0000-05 1/10W 0 ohm JW
Q211 192-4155-51 2SC4155 R410 033-1021-15 1/10W 1 k ohm (PE-3157B-A)
Q212 192-4116-51 2SC4116 G,L R411 033-4711-15 1/10W 470 ohm R548 119-0000-05 1/10W 0 ohm JW
Q212 192-4155-51 2SC4155 R412 033-2231-15 1/10W 22k ohm R550 119-0000-05 1/10W 0 ohm JW
Q403 125-4024-90 3DG3875 R413 033-4721-15 1/10W 4.7k ohm R553 119-0000-05 1/10W 0 ohm JW
Q404 125-2027-95 DTC143ZU R424 033-1231-15 1/10W 12k ohm R554 119-1021-15 1/10W 1k ohm
Q404 125-2041-96 RT1N436M R425 119-0000-05 1/10W 0 ohm JW R557 119-1021-15 1/10W 1k ohm
Q405 125-2198-90 KRC110S R427 033-1021-15 1/10W 1k ohm R633 033-1511-15 1/10W 150 ohm
Q409 125-0021-95
DTA143ZUA-T106
R428 033-1021-15 1/10W 1k ohm R634 033-1031-15 1/10W 10k ohm
Q409 125-0034-96 RT1P436M R429 033-1021-15 1/10W 1k ohm R635 033-1041-15 1/10W 100k ohm
Q410 125-4012-90 KTD1304 R430 033-1021-15 1/10W 1k ohm R636 033-1041-15 1/10W 100k ohm
