Clarion DB345MP Service Manual

- 14 -- 14 -
- 14 -- 14 -
- 14 -
DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MP
CCT207 050-0148-50 CCT 1K ohm
CCT208 050-0148-50 CCT 1K ohm
CCT209 050-0148-50 CCT 1K ohm
CCT210 050-0148-50 CCT 1K ohm
CCT211 050-0148-50 CCT 1K ohm
CCT212 050-0148-50 CCT 1K ohm
CCT213 050-0148-50 CCT 1K ohm
CCT214 050-0148-50 CCT 1K ohm
CCT215 050-0148-50 CCT 1K ohm
CCT216 050-0148-50 CCT 1K ohm
CCT217 050-0148-50 CCT 1K ohm
CCT218 050-0148-50 CCT 1K ohm
D201 001-0529-35 MA8062M
D601 001-0466-90 S5688B
D602 001-0466-90 S5688B
D603 001-0466-90 S5688B
D604 001-0466-90 S5688B
D605 001-0466-90 S5688B
D606 001-0466-90 S5688B
D607 001-0466-90 S5688B
D608 001-0466-90 S5688B
D609 001-1310-00 KDS160
D901 001-0592-00 RM4Z
D902 001-1310-00 KDS160
D903 001-0466-91 S5688G
D904 001-0330-90 1SS119
D905 001-0347-45 MA4082H
D906 001-0529-32 MA8056M
D907 001-0347-48 MA4091H
D908 001-0330-90 1SS119
D910 001-0347-32 MA4056M
D911 001-0330-90 1SS119
D912 001-0330-90 1SS119
D915 001-1310-00 KDS160
D916 001-1310-00 KDS160
D917 001-1310-00 KDS160
D918 001-0529-32 MA8056M
D920 001-0347-46 MA4091L
D925 001-0330-90 1SS119
D926 001-1310-00 KDS160
IC201 052-3933-00 uPD784215AYGC
-129-8EU
IC202 051-5413-09 S-80824KNUA
IC401 051-0869-58 NJM2103M
IC501 051-5033-90 PTC2311
IC502 051-3049-90 HA17558AF
IC601 051-2042-00 TA8275H
IC602 051-3019-90 NJM2060V
IC701 051-6704-00 TA94A20F
IC702 051-3327-90 TAR5S33
IC703 051-3326-90 TAR5S25
IC801 051-6201-90 LC72146M
J201 074-1316-12 12P
J501 074-1237-76 26P
J701 076-0349-04 4P
J901 074-1214-00 16P
L101 010-2003-04 COIL
L103 010-2330-67 5.6uH
L201 010-2330-62 2.2uH
L801 010-2330-86 220uH
Q101 125-2199-93 KRC103S
Q102 125-0199-98 KRA118S
Q103 125-0199-93 KRA103S
Q401 125-2199-93 KRC103S
Q521 125-0199-92 KRA102S
Q551 125-4010-90 KTC3875GR
Q552 125-4010-90 KTC3875GR
Q581 125-4010-90 KTC3875GR
Q582 125-4010-90 KTC3875GR
Q701 125-2199-93 KRC103S
Q702 125-2199-93 KRC103S
Q901 125-2199-93 KRC103S
Q902 125-3006-90 KTA1281
Q903 125-3004-90 KTA1504
Q904 125-4010-90 KTC3875GR
Q905 125-2199-92 KRC102S
Q906 125-0199-92 KRA102S
Q907 102-3420-00 2SC3420
Q908 125-0199-92 KRA102S
Q909 125-4011-90 KTA863YAT
Q910 125-4011-90 KTA863YAT
Q911 125-2199-93 KRC103S
Q912 125-0199-93 KRA103S
Q913 125-4011-90 KTA863YAT
Q914 125-4011-90 KTA863YAT
Q915 125-4011-90 KTA863YAT
Q916 125-3004-90 KTA1504GR
Q921 125-4010-90 KTC3875GR
Q922 125-2199-93 KRC103S
Q923 125-3009-90 KTA1272
Q924 125-2199-92 KRC102S
Q925 125-4011-90 KTA863YAT
Q928 125-0199-92 KRA102S
R101 119-2221-15 1/16W 2.2K ohm
R102 119-1011-15 1/16W 100 ohm
R103 119-2221-15 1/16W 2.2K ohm
R104 119-4741-15 1/16W 470K ohm
R105 119-1021-15 1/16W 1K ohm
R106 119-1831-15 1/16W 18K ohm
R108 060-0108-90 1/4WS 0 ohm
R110 060-0108-90 1/4WS 0 ohm
R111 119-0000-05 1/16W 0 ohm
R113 111-4721-98 1/4WS 4.7K ohm
R116 119-0000-05 1/16W 0 ohm
R121 119-0000-05 1/16W 0 ohm
R129 119-0000-05 1/16W 0 ohm
R130 119-0000-05 1/16W 0 ohm
R201 119-4721-15 1/16W 4.7K ohm
R202 119-2241-15 1/16W 220K ohm
R203 119-0000-05 1/16W 0 ohm
R204 119-1031-15 1/16W 10K ohm
R205 119-2241-15 1/16W 220K ohm
R206 119-2231-15 1/16W 22K ohm
R207 119-0000-05 1/16W 0 ohm
R208 119-0000-05 1/16W 0 ohm
R209 119-1021-15 1/16W 1K ohm
R210 119-1021-15 1/16W 1K ohm
R211 119-4721-15 1/16W 4.7K ohm
R212 119-1021-15 1/16W 1K ohm
R213 119-3311-15 1/16W 330 ohm
R214 119-4721-15 1/16W 4.7K ohm
R215 119-1021-15 1/16W 1K ohm
R216 119-1021-15 1/16W 1K ohm
R217 119-1031-15 1/16W 10K ohm @
R218 119-1031-15 1/16W 10K ohm #
R220 119-1031-15 1/16W 10K ohm
R221 119-1041-15 1/16W 100K ohm
R222 119-4731-15 1/16W 47K ohm
R223 119-0000-05 1/16W 0 ohm
R224 119-1021-15 1/16W 1K ohm
R225 119-1031-15 1/16W 10K ohm
R226 119-4731-15 1/16W 47K ohm
R227 119-1041-15 1/16W 100K ohm
R228 119-0000-05 1/16W 0 ohm
R229 119-0000-05 1/16W 0 ohm
R230 119-0000-05 1/16W 0 ohm
R231 119-0000-05 1/16W 0 ohm
R232 119-0000-05 1/16W 0 ohm
R234 119-1031-15 1/16W 10K ohm
R235 119-4731-15 1/16W 47K ohm
R236 119-1021-15 1/16W 1K ohm
R237 119-1031-15 1/16W 10K ohm
R238 119-1031-15 1/16W 10K ohm
R239 119-1031-15 1/16W 10K ohm
R240 119-1031-15 1/16W 10K ohm
R241 119-2221-15 1/16W 2.2K ohm
R242 119-1031-15 1/16W 10K ohm
R243 119-1031-15 1/16W 10K ohm
R401 119-4321-15 1/16W 4.3K ohm
R402 119-4731-15 1/16W 47K ohm
R403 119-1241-15 1/16W 120K ohm
R404 119-0000-05 1/16W 0 ohm
R405 119-8221-15 1/16W 8.2K ohm
R406 119-1541-15 1/16W 150K ohm
R407 119-4731-15 1/16W 47K ohm
R408 119-4731-15 1/16W 47K ohm
R409 119-0000-05 1/16W 0 ohm
R501 119-1031-15 1/16W 10K ohm
R502 119-1831-15 1/16W 18K ohm
R503 119-5621-15 1/16W 5.6K ohm
R504 119-2211-15 1/16W 220 ohm
R511 119-1031-15 1/16W 10K ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
