Clarion DB345MP Service Manual

DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MP
- 15 -- 15 -
- 15 -- 15 -
- 15 -
R512 119-1831-15 1/16W 18K ohm
R513 119-5621-15 1/16W 5.6K ohm
R514 119-2211-15 1/16W 220 ohm
R531 119-3901-15 1/16W 39 ohm
R532 119-3901-15 1/16W 39 ohm
R533 119-3901-15 1/16W 39 ohm
R534 119-3901-15 1/16W 39 ohm
R535 119-1231-15 1/16W 12K ohm
R536 119-1031-15 1/16W 10K ohm
R538 119-0000-05 1/16W 0 ohm
R539 119-0000-05 1/16W 0 ohm
R543 119-0000-05 1/16W 0 ohm
R550 119-4721-15 1/16W 4.7K ohm
R551 119-1031-15 1/16W 10K ohm
R552 119-3311-15 1/16W 330 ohm
R553 119-5621-15 1/16W 5.6K ohm
R554 119-1031-15 1/16W 10K ohm
R555 119-3311-15 1/16W 330 ohm
R556 119-5621-15 1/16W 5.6K ohm
R557 119-6811-15 1/16W 680 ohm
R558 119-6811-15 1/16W 680 ohm
R581 119-1031-15 1/16W 10K ohm
R582 119-3311-15 1/16W 330 ohm
R583 119-5621-15 1/16W 5.6K ohm
R584 119-1031-15 1/16W 10K ohm
R585 119-3311-15 1/16W 330 ohm
R586 119-5621-15 1/16W 5.6K ohm
R587 119-6811-15 1/16W 680 ohm
R588 119-6811-15 1/16W 680 ohm
R601 119-2221-15 1/16W 2.2K ohm
R602 119-2221-15 1/16W 2.2K ohm
R611 119-2221-15 1/16W 2.2K ohm
R612 119-2221-15 1/16W 2.2K ohm
R621 119-1031-15 1/16W 10K ohm
R622 119-2221-15 1/16W 2.2K ohm
R624 119-0000-05 1/16W 0 ohm
R631 119-5631-15 1/16W 56K ohm
R632 119-1031-15 1/16W 10K ohm
R633 119-1031-15 1/16W 10K ohm
R634 119-8231-15 1/16W 82K ohm
R635 119-8231-15 1/16W 82K ohm
R636 119-1031-15 1/16W 10K ohm
R637 119-1031-15 1/16W 10K ohm
R638 119-5631-15 1/16W 56K ohm
R639 119-5631-15 1/16W 56K ohm
R640 119-1031-15 1/16W 10K ohm
R641 119-1031-15 1/16W 10K ohm
R642 119-8231-15 1/16W 82K ohm
R643 119-8231-15 1/16W 82K ohm
R644 119-1031-15 1/16W 10K ohm
R645 119-1031-15 1/16W 10K ohm
R646 119-5631-15 1/16W 56K ohm
R647 060-0108-90 1/4WS 0 ohm
R706 119-4731-15 1/16W 47K ohm
R707 119-2231-15 1/16W 22K ohm
R711 119-4721-15 1/16W 4.7K ohm
R712 119-1821-15 1/16W 1.8K ohm
R713 119-4721-15 1/16W 4.7K ohm
R714 119-1821-15 1/16W 1.8K ohm
R715 119-4721-15 1/16W 4.7K ohm
R716 119-1821-15 1/16W 1.8K ohm
R717 119-4741-15 1/16W 470K ohm
R718 119-4741-15 1/16W 470K ohm
R719 119-1031-15 1/16W 10K ohm
R720 119-1031-15 1/16W 10K ohm
R721 119-4741-15 1/16W 470K ohm
R722 119-4731-15 1/16W 47K ohm
R730 119-4741-15 1/16W 470K ohm
R731 119-4741-15 1/16W 470K ohm
R732 119-4741-15 1/16W 470K ohm
R733 119-4741-15 1/16W 470K ohm
R734 119-4741-15 1/16W 470K ohm
R735 119-4741-15 1/16W 470K ohm
R736 119-4741-15 1/16W 470K ohm
R737 119-4741-15 1/16W 470K ohm
R738 119-4741-15 1/16W 470K ohm
R739 119-4741-15 1/16W 470K ohm
R740 119-4741-15 1/16W 470K ohm
R741 119-3311-15 1/16W 330 ohm
R742 119-3311-15 1/16W 330 ohm
R743 119-2251-15 1/16W 2.2M ohm
R744 119-2711-15 1/16W 270 ohm
R745 119-4741-15 1/16W 470K ohm
R801 119-0000-05 1/16W 0 ohm
R802 119-0000-05 1/16W 0 ohm
R803 119-0000-05 1/16W 0 ohm
R804 119-0000-05 1/16W 0 ohm
R805 119-5631-15 1/16W 56K ohm
R806 119-1021-15 1/16W 1K ohm
R807 119-2221-15 1/16W 2.2K ohm
R808 119-1031-15 1/16W 10K ohm
R809 119-1031-15 1/16W 10K ohm
R810 119-1041-15 1/16W 100K ohm
R811 119-1021-15 1/16W 1K ohm
R812 060-0108-90 1/4WS 0 ohm
R901 111-1521-98 1/4WS 1.5K ohm
R902 111-1221-98 1/4WS 1.2K ohm
R903 119-1031-15 1/16W 10K ohm
R904 111-1591-98 1/4WS 1.5 ohm
R905 111-1591-98 1/4WS 1.5 ohm
R906 111-1591-98 1/4WS 1.5 ohm
R907 111-1591-98 1/4WS 1.5 ohm
R908 119-1031-15 1/16W 10K ohm
R909 119-3321-15 1/16W 3.3K ohm
R910 119-3321-15 1/16W 3.3K ohm
R911 119-2231-15 1/16W 22K ohm
R912 111-4711-98 1/4WS 470 ohm
R913 111-4711-98 1/4WS 470 ohm
R914 119-2211-15 1/16W 220 ohm
R915 111-2291-98 1/4WS 2.2 ohm
R916 111-2291-98 1/4WS 2.2 ohm
R918 060-0108-90 1/4WS 0 ohm
R919 111-8211-98 1/4WS 820 ohm
R920 111-8211-98 1/4WS 820 ohm
R921 111-2291-98 1/4WS 2.2 ohm
R922 111-2291-98 1/4WS 2.2 ohm
R923 111-1021-98 1/4WS 1K ohm
R924 119-1231-15 1/16W 12K ohm
R925 119-1031-15 1/16W 10K ohm
R926 119-1021-15 1/16W 1K ohm
R927 060-0108-90 1/4WS 0 ohm
R928 060-0108-90 1/4WS 0 ohm
R929 119-0000-05 1/16W 0 ohm
R930 060-0108-90 1/4WS 0 ohm
R931 060-0108-90 1/4WS 0 ohm
R933 119-2231-15 1/16W 22K ohm
R934 119-4731-15 1/16W 47K ohm
R935 111-1021-98 1/4WS 1K ohm
R936 119-1031-15 1/16W 10K ohm
R937 111-4711-98 1/4WS 470 ohm
R938 119-0000-05 1/16W 0 ohm
R940 111-1831-98 1/4WS 18K ohm
R941 111-1021-98 1/4WS 1K ohm
R946 119-4731-15 1/16W 47K ohm
R953 060-0108-90 1/4WS 0 ohm
R954 060-0108-90 1/4WS 0 ohm
R956 060-0108-90 1/4WS 0 ohm
RCA501 075-0388-00 RCA JACK
RCA502 855-8000-08 RCA CORD
S401 013-3932-01 SW RESET
SUP101 060-0122-20 DSP-141N-S00B
T901 009-9006-60 CHOKE
X201 061-1081-50 12MHz
X701 061-9009-00 16.9344MHz
X801 061-1066-00 7.2MHz
PWB 039-2423-00 PWB (WITHOUT
COMPONENT)
C1 168-1022-55 50V 1000pF
C2 168-4732-78 50V 0.047uF
C3 168-4732-78 50V 0.047uF
C4 168-4732-78 50V 0.047uF
C5 042-0416-51 6.3V 10uF
C6 042-0416-51 6.3V 10uF
D1 001-0529-41 MA8075M
D2 001-7046-00 SPW310BS(LED)
D3 001-0529-29 MA8051M
D5 001-0529-41 MA8075M
D6 001-0529-41 MA8075M
D7 001-0529-41 MA8075M
D8 001-0529-41 MA8075M
D10 001-0529-29 MA8051M
D11 001-0529-41 MA8075M
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTIONREF No. PART No. DESCRIPTION
Main PWB (Switch) Section (B2)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTIONREF No. PART No. DESCRIPTION
