Clarion DB345MP Service Manual

- 16 -- 16 -
- 16 -- 16 -
- 16 -
DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MPDB345MP/DB346MP
DB345MP/DB346MP
IC1 051-6013-50 PT6554LQ
IR1 060-4008-00 RS-171
J1 076-0703-12 PLUG
LCD1 379-1278-41 INDICATOR
PL1 017-0410-00 14V 40mA
PL2 017-0410-00 14V 40mA
PL3 017-0410-00 14V 40mA
PL4 017-0410-00 14V 40mA
R1 119-2221-15 1/16W 2.2K ohm
R2 119-2221-15 1/16W 2.2K ohm
R3 119-2221-15 1/16W 2.2K ohm
R4 119-3921-15 1/16W 3.9K ohm
R5 119-1241-15 1/16W 120K ohm
R7 119-1031-15 1/16W 10K ohm
R8 119-4731-15 1/16W 47K ohm
R9 119-3311-15 1/16W 330 ohm
R10 119-3311-15 1/16W 330 ohm
R11 119-6801-15 1/16W 68 ohm
R14 119-3311-15 1/16W 330 ohm
R15 119-1011-15 1/16W 100 ohm
R16 119-1021-15 1/16W 1K ohm
R17 119-0000-05 1/16W 0 ohm
S1 013-6005-51 SKQNABD010
S2 013-6005-51 SKQNABD010
S3 013-6005-51 SKQNABD010
S4 013-6005-51 SKQNABD010
S5 013-6005-51 SKQNABD010
S6 013-6005-51 SKQNABD010
S7 013-6005-51 SKQNABD010
S8 013-6005-51 SKQNABD010
S9 013-6005-51 SKQNABD010
S10 013-6005-51 SKQNABD010
S11 013-6005-51 SKQNABD010
S12 013-6305-50 SKQMASE010
S13 013-6305-50 SKQMASE010
S14 013-6005-51 SKQNABD010
S15 013-6305-50 SKQMASE010
VR1 016-9900-92 VR W/SHAFT
PWB 039-2423-00 PWB (WITHOUT
COMPONENT)
C1 168-1042-78 16V 0.1uF
C3 163-2273-05 4V 220uF
C4 168-1042-78 16V 0.1uF
C5 163-1073-35 16V 100uF
C6 163-1073-35 16V 100uF
C7 168-1042-78 16V 0.1uF
C9 178-1052-78 1uF
C10 042-0560-85 6.3V 100uF
C11 046-4712-58 470pF
C12 178-1052-78 1uF
C13 046-4712-58 470pF
C15 168-1042-78 16V 0.1uF
C16 168-4732-78 0.047uF
C17 168-4732-78 0.047uF
C18 168-1042-78 16V 0.1uF
C19 168-1042-78 16V 0.1uF
C21 046-6822-58 6800pF
C22 046-3332-78 0.033uF
C24 178-1052-78 1uF
C25 168-1042-78 16V 0.1uF
C26 168-1042-78 16V 0.1uF
C28 168-1042-78 16V 0.1uF
C29 168-1042-78 16V 0.1uF
C30 045-6801-50 68pF
C31 168-1042-78 16V 0.1uF
C32 168-1042-78 16V 0.1uF
C33 046-1532-78 0.015uF
C34 168-1042-78 16V 0.1uF
C35 046-6812-58 680pF
C36 168-1042-78 16V 0.1uF
C37 168-1042-78 16V 0.1uF
C38 046-1522-58 1500pF
C39 046-4722-58 4700pF
C40 046-1032-78 0.01uF
C41 046-1532-78 0.015uF
C43 168-1042-78 16V 0.1uF
C47 045-4701-50 47pF
C48 168-1042-78 16V 0.1uF
C49 168-1042-78 16V 0.1uF
C50 042-0666-00 12.5V 22uF
C51 046-5622-58 5600pF
C52 178-1052-78 1uF
C55 178-1052-78 1uF
CCT2 050-0140-63 1/32W 47k ohm
x4J
D1 001-0367-91 1SS226
IC1 051-6071-08 BA5825FP-E2
IC2 051-6399-00 TC94A15F
J101 074-1228-76 26P
J201 074-1138-65 15P
J301 074-1138-60 10P
Q1 131-1188-50 2SB1188PQR
Q2 131-1188-50 2SB1188PQR
R1 117-6811-15 1/8W 680 ohm
R2 117-1001-15 1/8W 10 ohm
R9 033-2211-15 1/10W 220 ohm
R11 033-1051-15 1/10W 1M ohm
R12 119-6811-15 1/10W 680 ohm
R13 033-2211-15 1/10W 220 ohm
R14 033-2211-15 1/10W 220 ohm
R16 033-2231-15 1/10W 22k ohm
R18 033-3341-15 1/10W 330k ohm
R19 033-5621-15 1/10W 5.6k ohm
R21 033-2231-15 1/10W 22k ohm
R22 033-4731-15 1/10W 47k ohm
R24 033-1041-15 1/10W 100k ohm
R25 033-1031-15 1/10W 10k ohm
R26 033-1531-15 1/10W 15k ohm
R27 033-4731-15 1/10W 47k ohm
R28 033-1831-15 1/10W 18k ohm
R29 033-6821-15 1/10W 6.8k ohm
R30 033-8231-15 1/10W 82k ohm
R31 033-8231-15 1/10W 82k ohm
R32 119-1001-15 1/10W 10 ohm
R33 033-2731-15 1/10W 27k ohm
R34 033-2731-15 1/10W 27k ohm
R35 033-2731-15 1/10W 27k ohm
R36 033-2731-15 1/10W 27k ohm
R37 032-0162-50 1/10W 0.51 ohm
X1 060-1535-90 16.934MHz
PWB 039-2435-20 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
CD PWB section (B3) : CD Mechanism
Note:- Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
D1 001-7058-90 AN1105W-RR
D2 001-7058-90 AN1105W-RR
J1 074-1138-60 10P
Q1 060-4015-90 PS1192H
Q2 060-4015-90 PS1192H
S1 013-7414-50 CHUCKING
S2 013-7413-50 LIMIT
PWB 039-1944-21 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION
LED PWB section (B4) : CD mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTIONREF No. PART No. DESCRIPTION
