Clarion DXZ785USB Service Manual

NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1 ----------- SENSOR PWB 1 39 621-1750-20 POWER GEAR C 1
2 966-1743-21 DRIVE-PLT-ASSY 1 40 621-1751-20 POWER GEAR D 1
3 SMA-182-100 SPINDLE MOTOR-ASSY 1 41 621-1752-20 DISC STOPPER 1
4 SMA-197-100 SLED MOTOR-ASSY 1 42 621-1753-20 CLAMPER RING 1
5 345-5476-20 CUSHION RUBBER 1 43 621-1754-20 GEAR BASE 1
6 620-1023-23 CLAMPER PLATE 1 44 622-1571-21 ROLLER SHAFT 1
7 620-1026-21 SPRING PLATE 1 45 624-0020-00 LEAD SCREW 1
8 620-1596-23 CLAMPER LINK 1 46 629-0081-21 DAMPER F 2
9 620-1598-22 UPPER CHASSIS 1 47 629-0082-21 DAMPER R 1
10 620-1752-20 SENSOR ARM 1 48 716-1507-01 SCREW(M2x3) 1
11 620-1753-20 ID-LOCK PLATE 1 49 716-1670-01 SCREW(M2x4) 4
12 620-1766-20 LOWER CHASSIS 1 50 716-1733-01 SCREW(M1.7x2.3) 2
13 621-0608-21 SECOND GEAR 1 51 716-3469-01 SCREW(1.7x4) 2
14 621-0609-20 BASE GEAR 1 52 716-3473-01 SCREW(M2x3) 1
15 621-0610-20 IDLE GEAR A 1 53 716-3551-00 SCREW(M1.4x2.5) 2
16 621-0611-20 IDLE GEAR B 1 54 750-7865-20 SHIFT SPRING 1
17 621-0612-21 ROLLER GEAR A 1 55 750-7866-20 RACK SPRING 1
18 621-0620-20 THREAD GEAR A 1 56 750-7867-20 CLAMPER SPRING 1
19 621-0621-20 THREAD GEAR B 1 57 750-7868-20 ID-LOCK SPRING 1
20 621-0623-23 LS-HOLDER 1 58 750-7869-20 SENSOR SPRING 1
21 621-0624-22 GUIDE RAIL 1 59 750-7870-20 DR-SPRING F 2
22 621-0711-21 LOADING ROLLER 2 60 750-7871-20 DR-SPRING RA 1
23 621-0718-21 ROLLER GUIDE 1 61 750-7872-20 DR-SPRING RB 1
24 621-0719-20 ROLLER GEAR 1 62 750-7873-20 DR-SPRING C 1
25 621-0720-20 ROLLER GEAR C 1 63 750-6797-20 ROLLER SPRING L 1
26 621-0721-20 ROLLER GEAR D 1 64 750-6798-20 ROLLER SPRING R 1
27 621-0728-20 STOPPER LINK 1 65 714-2003-8B SCREW(M2x3) 2
28 621-1719-20 IDLE CASE 1 66 780-2025-00 SCREW(M2x2.5) 3
29 621-1726-20 ROLLER SLEEVE 2 67 781-1730-00 SCREW(M1.7x3) 1
30 621-1729-20 SH-BASE 1 68 803-4906-60 VINYL-COAT-WIRE(ORG) 1
31 621-1742-20 UPPER GUIDE 1 69 9 69-0071-30 PICKUP-ASSY 1
32 621-1743-20 SHIFT LEVER 1 70 816-2590-00 SPECIAL LEAD(GRN) 1
33 621-1744-20 RACK 1 71 816-2591-00 SPECIAL LEAD(YEL) 1
34 621-1745-20 LOCK ARM L 1 72 816-2592-00 SPECIAL LEAD(BLUE) 1
35 621-1746-20 LOCK ARM R 1 73 816-2593-00 SPECIAL LEAD(PUR) 1
36 621-1747-20 GEAR COVER 1 74 966-1722-20 SH-RACK-ASSY 1
37 621-1748-20 POWER GEAR A 1 75 816-2624-50 FLAT WIRE 1
38 621-1749-20 POWER GEAR B 1
-8-
DXZ785USB/DXZ786USB
EXPLODED VIEW / PARTS LIST
CD mechanism section: 929-5016-80
* The exploded view is on page 9
pin 22
:
NC
:
-
:
Not in use.
pin 23
:
NC
:
-
:
Not in use.
pin 24
:
NC
:
-
:
Not in use.
pin 25
:
NC
:
-
:
Not in use.
pin 26
:
NC
:
-
:
Not in use.
pin 27
:
NC
:
-
:
Not in use.
pin 28
:
NC
:
-
:
Not in use.
pin 29
:
NC
:
-
:
Not in use.
pin 30
:
NC
:
-
:
Not in use.
pin 31
:
NC
:
-
:
Not in use.
pin 32
:
CLOCK_OUT
:
O
:
32.768 kHz clock output, if selected by
CLOCK_ENAB.
pin 33
:
NC
:
-
:
Not in use.
pin 34
:
NC
:
-
:
Not in use.
pin 35
:
NC
:
-
:
Not in use.
pin 36
:
NC
:
-
:
Not in use.
pin 37
:
NC
:
-
:
Not in use.
pin 38
:
nRESET
:
I
:
CP reset(active low).
pin 39
:
VSS
:
-
:
Supply voltage, negative terminal.
pin 40
:
VCC
:
-
:
Supply volltage positive terminal.
