Clarion DXZ785USB Service Manual

-13-
DXZ785USB/DXZ786USB
ELECTRICAL PARTS LIST
Main PWB (B1) section
2. Some parts depend on each model.
The model name is specified in the description.
Note)1. Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT1
092-2215-50
ANT-RECEPT C314 043-1804-90 0.1uF C380 043-1735-90 100pF
BL1 880-2091E TUNER C315 043-1735-90 100pF C382 043-1611-90 2200pF
C2 043-1719-90 22pF C316 043-1735-90 100pF C382 046-2222-58 2200pF
C3 042-1631-50 10V 100uF C317 043-1735-90 100pF C383 043-1611-90 2200pF
C4 043-1802-90 0.01uF C318 043-1802-90 0.01uF C383 046-2222-58 2200pF
C5 043-1821-90 0.022uF C320 043-1804-90 0.1uF C384 043-1819-90 2200pF
C7 043-1800-90 1000pF C321 043-1735-90 100pF C385 043-1819-90 2200pF
C8 187-4763-15 6.3V 47uF C322 042-0654-52 6.3V 10uF C386 043-1819-90 2200pF
C9 043-1608-90 0.1uF C324 043-1804-90 0.1uF C387 043-1819-90 2200pF
C9 046-1042-78 0.1uF C325 043-0552-90 6.3V 47uF C402 042-1563-71 16V 100uF
C10 043-1804-90 0.1uF C327 043-1824-91 0.22uF C409 042-1563-71 16V 100uF
C11 043-1739-90 150pF C327 168-2245-79 0.22uF C410 043-1804-90 0.1uF
C12 043-1735-90 100pF C329 043-0540-00 6.3V 10uF C411 043-0540-00 6.3V 10uF
C13 043-1735-90 100pF C330 043-1841-90 0.047uF C412 043-0540-00 6.3V 10uF
C14 043-1800-90 1000pF C331 043-1608-90 0.1uF C413 043-0540-00 6.3V 10uF
C15 043-0552-90 6.3V 47uF C331 046-1042-78 0.1uF C414 043-0540-00 6.3V 10uF
C101 042-1715-00 16V 3300uF C332 163-2273-25 10V 220uF C415 043-0540-00 6.3V 10uF
C102 172-1041-15 0.1uF C333 043-1804-90 0.1uF C416 043-0540-00 6.3V 10uF
C103 189-1083-12 6.3V 1000uF C334 043-1711-90 10pF C417 043-0540-00 6.3V 10uF
C104 042-0654-52 6.3V 10uF C335 043-1824-91 0.22uF C418 043-0540-00 6.3V 10uF
C105 042-0654-52 6.3V 10uF C335 168-2245-79 0.22uF C419 043-0540-00 6.3V 10uF
C106 042-0654-52 6.3V 10uF C336 043-1821-90 0.022uF C420 043-0540-00 6.3V 10uF
C107 042-0654-52 6.3V 10uF C337 043-1606-90 1000pF C421 043-0540-00 6.3V 10uF
C108 042-0654-52 6.3V 10uF C337 046-1022-58 1000pF C422 043-0540-00 6.3V 10uF
C109 042-0654-52 6.3V 10uF C338 043-1606-90 1000pF C423 043-0264-52 1000pF
C110 163-2253-65 50V 2.2uF C338 046-1022-58 1000pF C424 043-1731-90 68pF
C114 178-4742-78 0.47uF C340 043-1751-90 470pF C425 043-1731-90 68pF
C115 178-4742-78 0.47uF C341 043-1821-90 0.022uF C426 043-0264-52 1000pF
C116 178-4742-78 0.47uF C342 043-1821-90 0.022uF C427 043-0264-51 2200pF
C117 178-4742-78 0.47uF C343 043-1711-90 10pF C428 043-1735-90 100pF
C119 163-1053-65 50V 1uF C344 043-0540-02 16V 1uF C429 043-1735-90 100pF
C120 163-1063-35 16V 10uF C345 043-1821-90 0.022uF C430 043-0264-51 2200pF
C121 043-1802-90 0.01uF C346 043-1821-90 0.022uF C431 043-0264-51 2200pF
C124 043-1804-90 0.1uF C347 043-1802-90 0.01uF C432 043-1735-90 100pF
C125 043-1800-90 1000pF C350 043-0540-00 6.3V 10uF C433 043-1735-90 100pF
C126 043-1800-90 1000pF C351 043-1751-90 470pF C434 043-0264-51 2200pF
C127 043-1800-90 1000pF C352 043-1821-90 0.022uF C435 043-1731-90 68pF
C128 043-1800-90 1000pF C355 043-1804-90 0.1uF C436 043-1735-90 100pF
C129 043-1800-90 1000pF C356 043-1606-90 1000pF C437 043-1735-90 100pF
C130 043-1800-90 1000pF C356 046-1022-58 1000pF C438 043-1731-90 68pF
C131 043-1800-90 1000pF C357 043-1741-90 180pF C439 043-1735-90 100pF
C132 043-1800-90 1000pF C357 166-1811-50 180pF C440 043-1735-90 100pF
C133 043-1711-90 10pF C358 043-0551-90 6.3V 4.7uF C441 043-1804-90 0.1uF
C134 043-1711-90 10pF C359 043-0551-90 6.3V 4.7uF C442 043-0264-52 1000pF
C135 043-1711-90 10pF C360 043-1800-90 1000pF C443 043-0264-52 1000pF
C136 043-1711-90 10pF C361 042-0654-52 6.3V 10uF C444 043-0264-51 2200pF
C137 043-1800-90 1000pF C362 043-0551-90 6.3V 4.7uF C445 043-0264-51 2200pF
C138 043-1800-90 1000pF C363 043-1821-90 0.022uF C446 043-0264-51 2200pF
C139 043-1800-90 1000pF C364 043-1831-90 0.033uF C447 043-0264-51 2200pF
C140 043-1800-90 1000pF C365 043-1804-90 0.1uF C452 163-1063-35 16V 10uF
C301 178-4742-78 0.47uF C366 043-1735-90 100pF C600 042-1563-71 16V 100uF
C302 043-0540-00 6.3V 10uF C367 043-1821-90 0.022uF C601 043-1804-90 0.1uF
C303 163-1073-15 6.3V 100uF C368 043-1608-90 0.1uF C602 163-2263-35 16V 22uF
C304 043-1601-90 100pF C368 046-1042-78 0.1uF C603 043-1841-90 0.047uF
C304 045-1011-50 100pF C369 043-0551-90 6.3V 4.7uF C604 043-1735-90 100pF
C305 043-1601-90 100pF C370 042-0654-52 6.3V 10uF C605 042-1631-50 10V 100uF
C305 045-1011-50 100pF C371 043-1608-90 0.1uF C606 043-1606-90 1000pF
C306 043-0540-00 6.3V 10uF C371 046-1042-78 0.1uF C606 046-1022-58 1000pF
C307 043-0540-00 6.3V 10uF C372 042-0654-52 6.3V 10uF C607 043-1606-90 1000pF
C308 043-0540-00 6.3V 10uF C373 043-1608-90 0.1uF C607 046-1022-58 1000pF
C309 043-0540-00 6.3V 10uF C373 046-1042-78 0.1uF C608 187-4763-35 16V 47uF
C310 043-0540-00 6.3V 10uF C374 043-0552-90 6.3V 47uF C609 043-1602-90 18pF
C311 043-1606-90 1000pF C376 043-1821-90 0.022uF C609 045-1801-50 18pF
C311 046-1022-58 1000pF C377 043-1608-90 0.1uF C610 043-1603-90 22pF
C312 043-1606-90 1000pF C377 046-1042-78 0.1uF C610 045-2201-50 22pF
C312 046-1022-58 1000pF C378 043-1601-90 100pF C611 042-1631-50 10V 100uF
C313 043-1606-90 1000pF C378 045-1011-50 100pF C612 043-1804-90 0.1uF
C313 046-1022-58 1000pF C379 043-1735-90 100pF C613 187-4763-35 16V 47uF
