Clarion DXZ838RMP User Manual

DXZ838RMP 27
English
Operations Common to Each Mode
● LEFT:
Telephone calls can be heard on the front left
speaker connected to this unit.
4. Press the [T] button to return to the previous
mode.
Cellular phone interrupt setting
If you connect this unit and your cellular phone
with a separately sold cable, you can listen to
your telephone calls on your car speakers.
∗ The factory default setting is “OFF”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button to select “TEL-
SWITCH”.
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise to select the setting. Each time
you turn the [ROTARY] knob, the setting
changes in the following order:
OFF ➜ ON ➜ MUTE ➜ OFF...
● OFF:
This unit continues normal operation even
when the cellular phone is used.
Note:
• If conncting a hands-free kit, please ensure the
setting is ON to receive the telephone audio
through the system.
● ON:
You can listen to your telephone calls from
the speakers connected to this unit.
∗ When listening to your calls on your car
speakers, you can adjust the volume by turn-
ing the [ROTARY] knob.
● MUTE:
The sound from this unit is muted during
telephone calls.
4. Press the [T] button to return to the previous
mode.
Setting the button illumination
Press the [COLOR] button to select a color
type. Each time you press the [COLOR] button,
the type changes in the following orders:
COLOR SCAN ➜ Indigo Blue ➜ Surf Blue ➜
Silky White ➜ Aqua Green ➜ Fresh Green ➜
Leaf Green ➜ Moon Yellow ➜ Warm Amber
➜ Pale Orange ➜ Passion Red ➜ Vivid Pink
➜ Dark Violet ➜ USER COLOR 1 ➜ USER
COLOR 2 ➜ USER COLOR 3...
● Setting COLOR SCAN mode
As selecting “COLOR SCAN”, the color auto-
matically changes.
∗ The factory default setting is “COLOR SCAN”.
∗ After 3 second the color change to the other.
● Setting USER mode
The factory default setting is “R
ÎÎ
ÎÎ
Î
8 G
ÎÎ
ÎÎ
Î
8 B
ÎÎ
ÎÎ
Î
8”.
As selecting “USER COLOR 1, 2, 3”, press and
hold the [COLOR] button 1 second or longer
“R
ÎÎ
ÎÎ
Î
8 G
ÎÎ
ÎÎ
Î
8 B
ÎÎ
ÎÎ
Î
8” appears in the display.
1. Press the [a] or [d] button to move the
cursor.
2. Turn the [ROTARY] knob to select from 0 to
8.
3. Press and hold the [ ] button for 2 sec-
onds or longer to store the color in memory
and cancel setting mode.
Setting auto volume
1. Press and hold the [T] button for 1 second or
longer and enter “ADJ” mode
2. Press the [a] or [d] button to select
the”CALIBRATE ”
3. Press the [ ] button and “START ” is
displayed.
4. Keep driving speed 50km/h and press the
[ ] button.
5. “CALIBRATION” is flush for 2 seconds in
display.
6. If calibration is successful display indicate
“SUCCESSFUL”, or if calibration is not suc-
cessful display indicate “FAILED”.
COLOR
Indigo Blue
Surf Blue
Silky White
Aqua Green
Fresh Green
Leaf Green
Moon Yellow
Warm Amber
Pale Orange
Passion Red
Vivid Pink
Dark Violet
USER COLOR 1
USER COLOR 2
USER COLOR 3
R
0
0
6
0
0
3
8
8
8
8
8
3
8
8
8
G
0
4
8
8
8
8
6
3
2
0
0
0
8
8
8
B
8
8
8
2
0
0
0
0
0
0
3
8
8
8
8

Clarion DXZ838RMP Specifications

Radio Section

FM receiving frequencies	87.5 to 108 MHz (0.05 MHz steps)
MW receiving frequencies	531 to 1602 kHz (9 kHz steps)
LW receiving frequencies	153 to 279 kHz (3 kHz steps)

CD Player Section

frequency response	5 Hz to 20 kHz (± 1 dB)
signal to noise ratio	100 dB (1 kHz) IHF-A
dynamic range	95 dB (1 kHz)

General Specifications

output power	4 ✕ 31 W (DIN 45324, +B=14.4V)
power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
power consumption	Less than 15 A

Weight and Dimensions

main unit weight	1.6 kg
remote control unit weight	30 g (including battery)
main unit dimensions	178 (W) ✕ 50 (H) ✕ 155 (D) mm
