Clarion DXZ838RMP User Manual

26 DXZ838RMP
English
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button and select
“AUX/TEL”.
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise as needed and select from
“AUX” or “TEL”.
● AUX :
AUX/TEL input cable is for external Audio input.
● TEL :
AUX/TEL input cable is for cellular phone au-
dio input.
4. Press the [T] button to return to the previous
mode.
Selecting AUX IN sensitivity
Make the following settings to select the sensi-
tivity when sounds from external devices con-
nected to this unit are difficult to hear even after
adjusting the volume.
∗ The factory default setting is “AUX LOW”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button and select
“AUX SENS”.
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise as needed and select from
“AUX HIGH”, “AUX MID” or “AUX LOW”.
4. Press the [T] button to return to the previous
mode.
Setting the car speaker output for
the cellular phone
∗ The factory default setting is “RIGHT”.
∗ To output the telephone calls, set the cellular phone
interrupt to ON.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button to select “TEL
SPEAKER”.
3. Turn the [ROTARY] knob clockwise to select
“RIGHT” or counterclockwise to select
“LEFT”.
● RIGHT:
Telephone calls can be heard on the front
right speaker connected to this unit.
Operations Common to Each Mode
2. Press the [a] or [d] button and select
“BLINK LED”.
3. Turn the [ROTARY] knob clockwise to set
this function “ON” or turn it counterclockwise
to switch this function “OFF”.
4. Press the [T] button to return to the previous
mode.
Setting the Subwoofer
∗ The factory default setting is “SUB-W ON”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button and select
“SUB-WOOFER”.
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise and select “ON” or “OFF”.
4. Press the [T] button to return to the previous
mode.
Setting LOW PASS FILTER
∗ The factory default setting is “THRGH”.
1. Press and hold the [T] button for 1 second or
longer to switch to the adjustment selection
display.
2. Press the [a] or [d] button and select
“SUB-W LPF”.
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise to select the setting. Each time
you turn the [ROTARY] knob, the setting
changes in the following order:
THRGH ➜ LPF 50 ➜ LPF 80 ➜ LPF 120
4. Press the [T] button to return to the previous
mode.
AUX function
This system has an external input jack so you
can listen to sounds and music from external
devices when connected to this unit.
Selecting AUX/TEL
You can listen to sounds and music from exter-
nal devices or your telephone calls from the
speakers when connected to this unit.
When TEL INT or External device is connected to
this unit, you can select TEL mode or AUX mode.
∗ The factory default setting is “AUX”.

Clarion DXZ838RMP Specifications

Radio Section

FM receiving frequencies	87.5 to 108 MHz (0.05 MHz steps)
MW receiving frequencies	531 to 1602 kHz (9 kHz steps)
LW receiving frequencies	153 to 279 kHz (3 kHz steps)

CD Player Section

frequency response	5 Hz to 20 kHz (± 1 dB)
signal to noise ratio	100 dB (1 kHz) IHF-A
dynamic range	95 dB (1 kHz)

General Specifications

output power	4 ✕ 31 W (DIN 45324, +B=14.4V)
power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
power consumption	Less than 15 A

Weight and Dimensions

main unit weight	1.6 kg
remote control unit weight	30 g (including battery)
main unit dimensions	178 (W) ✕ 50 (H) ✕ 155 (D) mm
