28 DXZ838RMP
English
Operations Common to Each Mode
7. If you failed, repeat steps 3 to 6.
Note:
• When installing this device or transferring it into
another vehicle, for the sake of safety, always
have this work done by the store of purchase or
your nearest Clarion dealer. Installation requires
specialized techniques and experience.
Setting auto volume sensitivity
1. Press and hold the [T] button for 1 second or
longer and enter “ADJ” mode
2. Press the [a] or [d] button to select the
“A-VOL SENS”
3. Turn the [ROTARY] knob clockwise or coun-
terclockwise to make the adjustment.
The adjustment steps are below 6 steps, Off
➜ Low ➜ M-L ➜ Mid ➜ M-H ➜ High.
Entering titles
Titles up to 8 characters long can be stored in
memory and displayed for CD, CD changer and
TV stations. The number of titles that can be en-
tered for each mode are as follows.
Mode Number of titles
CD mode 50 titles
TV mode 20 titles
TUNER mode 30 titles
CD changer mode Number of titles
DCZ625 connected 100 titles
CDC655Tz connected 100 titles
CDC1255z connected 50 titles
1. Press the [FNC] button to select the mode
you want to enter a title (CD, CD changer or
TV).
2. Select and play a CD in the CD changer or
tune in to a TV station for which you want to
enter the title.
3. Press the [D] button and display the main.
4. Press the [T] button.
5. Press the [a] or [d] button to move the
cursor.
6. Press the [D] button to select a character.
Each time you press the [D] button, the char-
acter changes in the following order:
Capital letters ➜ Small letters ➜ Numbers/
Symbols ➜ Umlaut ➜ Capital letters...
7. Turn the [ROTARY] knob to select the de-
sired character.
8. Repeat steps 5 to 7 to enter up to 8 charac-
ters for the title.
9. Press and hold the [ ] button for 2 sec-
onds or longer to store the title into memory
and cancel title input mode.
Clearing titles
1. Select and play a CD in the CD changer or
tune in to a TV station for which you want to
clear the title.
2. Press the [D] button and display the main.
3. Press the [T] button and switch the display to
the title input display.
4. Press the [BND] button.
5. Press and hold the [ ] button for 2 sec-
ond or longer to clear the title and cancel title
input mode.

Clarion DXZ838RMP Specifications

Radio Section

FM receiving frequencies	87.5 to 108 MHz (0.05 MHz steps)
MW receiving frequencies	531 to 1602 kHz (9 kHz steps)
LW receiving frequencies	153 to 279 kHz (3 kHz steps)

CD Player Section

frequency response	5 Hz to 20 kHz (± 1 dB)
signal to noise ratio	100 dB (1 kHz) IHF-A
dynamic range	95 dB (1 kHz)

General Specifications

output power	4 ✕ 31 W (DIN 45324, +B=14.4V)
power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
power consumption	Less than 15 A

Weight and Dimensions

main unit weight	1.6 kg
remote control unit weight	30 g (including battery)
main unit dimensions	178 (W) ✕ 50 (H) ✕ 155 (D) mm
