Clarion DXZ838RMP User Manual

12 DXZ838RMP
English
6. OPERATIONS
Basic Operations
Note:Be sure to read this chapter referring to the front diagrams of
chapter “2. CONTROLS” on page 5 (unfold).
CAUTION
Be sure to lower the volume before switch-
ing off the unit power or the ignition key. The
unit remembers its last volume setting. If
you switch the power off with the volume up,
when you switch the power back on, the
sudden loud volume may hurt your hearing
and damage the unit.
Turning on/off the power
Note:
• Be careful about using this unit for a long time
without running the engine. If you drain the car’s
battery too far, you may not be able to start the
engine and this can reduce the service life of the
battery.
1. Press the [FNC] button.
2. The illumination and display on the unit light
up. The unit automatically remembers its last
operation mode and will automatically switch
to display that mode.
3. Press and hold the [FNC] button for 1 sec-
ond or longer to turn off the power for the
unit.
Note:
• System check
The first time this unit is turned on after the wire
connections are completed, it must be checked
what equipment is connected. When the power is
turned on, “SYSTEM CHCK” and “Push POWER”
appear in the display alternately, so press the
[FNC] button. The system check starts within the
unit. When the system check is complete, press
the [FNC] button again.
Selecting a mode
1. Press the [FNC] button to change the opera-
tion mode.
2. Each time you press the [FNC] button, the
operation mode changes in the following or-
der:
Radio mode ➜ DAB mode ➜ CD/MP3/WMA
mode ➜ DVD Deck mode ➜ CD changer
mode ➜ MD changer mode ➜ DVD changer
mode ➜ TV mode ➜ AUX mode ➜ Radio
mode...
∗ External equipment not connected with
CeNET is not displayed.
Adjusting the volume
Turning the [ROTARY] knob clockwise in-
creases the volume; turning it counterclockwise
decreases the volume.
∗ The volume level is from 0 (minimum) to 33 (maxi-
mum).
Switching the display
Press the [D] button to select the desired display.
Each time you press the [D] button, the display
switches in the following order:
Main display ➜ Clock (CT) display ➜
Main display
∗ Once selected, the preferred display becomes
the display default. When a function adjust-
ment such as volume is made, the screen will
momentarily switch to that function’s display,
then revert back to the preferred display sev-
eral seconds after the adjustment.
∗ For information on how to enter a title, refer to
the subsection “Entering titles” in section
“Operations Common to Each Mode”.
∗ When CT data is not received, “CT––:––” ap-
pears in the display.
Setting the Beat EQ
This unit are provided with 4 types of sound
tone effects stored in memory. Select the one
you prefer.
∗ The factory default setting is “USER CUSTOM”.
Each time you press the [BEQ] button, the tone
effect changes in the following order:
“BASS BOOST” ➜ “IMPACT” ➜ “EXCITE” ➜
“USER CUSTOM” ➜ “TONE BYPASS” ➜
“BASS BOOST” ...
• BASS BOOST : bass emphasized
• IMPACT : bass and treble empha-
sized
• EXCITE : bass and treble empha-
sized mid de-emphasized
• USER CUSTOM : user custom
• TONE BYPASS : no sound effect

Clarion DXZ838RMP Specifications

Radio Section

FM receiving frequencies	87.5 to 108 MHz (0.05 MHz steps)
MW receiving frequencies	531 to 1602 kHz (9 kHz steps)
LW receiving frequencies	153 to 279 kHz (3 kHz steps)

CD Player Section

frequency response	5 Hz to 20 kHz (± 1 dB)
signal to noise ratio	100 dB (1 kHz) IHF-A
dynamic range	95 dB (1 kHz)

General Specifications

output power	4 ✕ 31 W (DIN 45324, +B=14.4V)
power supply voltage	14.4 V DC (10.8 to 15.6 V allowable)
power consumption	Less than 15 A

Weight and Dimensions

main unit weight	1.6 kg
remote control unit weight	30 g (including battery)
main unit dimensions	178 (W) ✕ 50 (H) ✕ 155 (D) mm
