EF-1080I-C
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Q615 125-8004-00 MTAJ30N06HD
Q616 100-1298-00 2SA1298
Q617 102-2712-00 2SC2712
R101 117-1531-10 1/10W 15kΩ
R102 032-0092-21 1/10W 3.3kΩ±1%
R103 032-0092-21 1/10W 3.3kΩ±1%
R104 032-0139-50 1/10W 4.7kΩ
R105 032-0139-50 1/10W 4.7kΩ
R106 117-2721-10 1/10W 2.7kΩ
R107 117-3321-10 1/10W 3.3kΩ
R108 117-2241-10 1/10W 220kΩ
R109 117-4711-10 1/10W 470Ω
R110 117-2241-10 1/10W 220kΩ
R111 117-4721-10 1/10W 4.7kΩ
R112 117-3321-10 1/10W 3.3kΩ
R113 111-4731-91 1/4WS 47kΩ
R115 111-5611-91 1/4WS 560Ω
R116 111-5621-91 1/4WS 5.6kΩ
R117 111-3321-91 1/4WS 3.3kΩ
R119 111-5611-91 1/4WS 560Ω
R120 111-4731-91 1/4WS 47kΩ
R121 111-4731-91 1/4WS 47kΩ
R123 111-5611-91 1/4WS 560Ω
R124 111-8211-91 1/4WS 820Ω
R126 111-1821-91 1/4WS 1.8kΩ
R127 111-5611-91 1/4WS 560Ω
R128 111-4731-91 1/4WS 47kΩ
R129 111-4731-91 1/4WS 47kΩ
R130 111-1521-91 1/4WS 1.5kΩ
R131 111-5611-91 1/4WS 560Ω
R133 111-2711-91 1/4WS 270Ω
R135 111-5611-91 1/4WS 560Ω
R136 111-4731-91 1/4WS 47kΩ
R137 117-4731-10 1/10W 47kΩ
R138 117-2221-10 1/10W 2.2kΩ
R139 117-1051-10 1/10W 1MΩ
R140 117-1051-10 1/10W 1MΩ
R141 117-1021-10 1/10W 1kΩ
R142 117-4731-10 1/10W 47kΩ
R143 117-4731-10 1/10W 47kΩ
R144 117-1531-10 1/10W 15kΩ
R145 117-1221-10 1/10W 1.2kΩ
R146 117-3941-10 1/10W 390kΩ
R147 117-2031-10 1/10W 20kΩ
R148 111-4791-91 1/4WS 4.7Ω
R201 117-1531-10 1/10W 15kΩ
R202 032-0092-21 1/10W 3.3kΩ±1%
R203 032-0092-21 1/10W 3.3kΩ±1%
R204 032-0139-50 1/10W 4.7kΩ
R205 032-0139-50 1/10W 4.7kΩ
R206 117-2721-10 1/10W 2.7kΩ
R207 117-3321-10 1/10W 3.3kΩ
R208 117-2241-10 1/10W 220kΩ
R209 117-4711-10 1/10W 470Ω
R210 117-2241-10 1/10W 220kΩ
R211 117-3321-10 1/10W 3.3kΩ
R212 117-4721-10 1/10W 4.7kΩ
R213 111-4731-91 1/4WS 47kΩ
R214 111-5611-91 1/4WS 560Ω
R216 111-5621-91 1/4WS 5.6kΩ
R217 111-3321-91 1/4WS 3.3kΩ
R218 111-5611-91 1/4WS 560Ω
R220 111-4731-91 1/4WS 47kΩ
R221 111-4731-91 1/4WS 47kΩ
R222 111-5611-91 1/4WS 560Ω
R224 111-8211-91 1/4WS 820Ω
R226 111-5611-91 1/4WS 560Ω
R227 111-1821-91 1/4WS 1.8kΩ
R228 111-4731-91 1/4WS 47kΩ
R229 111-4731-91 1/4WS 47kΩ
R230 111-5611-91 1/4WS 560Ω
R231 111-1521-91 1/4WS 1.5kΩ
R233 111-2711-91 1/4WS 270Ω
R234 111-5611-91 1/4WS 560Ω
R236 111-4731-91 1/4WS 47kΩ
R237 117-4731-10 1/10W 47kΩ
R238 117-2221-10 1/10W 2.2kΩ
R239 117-4731-10 1/10W 47kΩ
R240 117-1051-10 1/10W 1MΩ
R241 117-1051-10 1/10W 1MΩ
R242 117-1021-10 1/10W 1kΩ
R243 117-4731-10 1/10W 47kΩ
R244 117-1531-10 1/10W 15kΩ
R245 117-1221-10 1/10W 1.2kΩ
R246 117-3941-10 1/10W 390kΩ
R247 117-2031-10 1/10W 20kΩ
R248 111-4791-91 1/4WS 4.7Ω
R301 117-1531-10 1/10W 15kΩ
R302 032-0092-21 1/10W 3.3kΩ±1%
R303 032-0092-21 1/10W 3.3kΩ±1%
R304 032-0139-50 1/10W 4.7kΩ
R305 032-0139-50 1/10W 4.7kΩ
R306 117-2721-10 1/10W 2.7kΩ
R307 117-3321-10 1/10W 3.3kΩ
R308 117-2241-10 1/10W 220kΩ
R309 117-4711-10 1/10W 470Ω
R310 117-2241-10 1/10W 220kΩ
R311 117-4721-10 1/10W 4.7kΩ
R312 117-3321-10 1/10W 3.3kΩ
R313 111-4731-91 1/4WS 47kΩ
R314 060-0108-00 1/6ZP 0Ω JW
R315 111-5611-91 1/4WS 560Ω
R317 111-1811-91 1/4WS 180Ω
R319 111-5611-91 1/4WS 560Ω
R320 111-4731-91 1/4WS 47kΩ
R321 111-4731-91 1/4WS 47kΩ
R322 111-1811-91 1/4WS 180Ω
R323 111-5611-91 1/4WS 560Ω
R325 111-2721-91 1/4WS 2.7kΩ
R327 111-5611-91 1/4WS 560Ω
R328 111-4731-91 1/4WS 47kΩ
R329 111-4731-91 1/4WS 47kΩ
R330 111-1031-91 1/4WS 10kΩ
R331 111-5611-91 1/4WS 560Ω
R336 111-4731-91 1/4WS 47kΩ
R337 117-4731-10 1/10W 47kΩ
R338 117-2221-10 1/10W 2.2kΩ
R339 117-1051-10 1/10W 1MΩ
R340 117-1051-10 1/10W 1MΩ
R341 117-1021-10 1/10W 1kΩ
R342 117-4731-10 1/10W 47kΩ
R343 117-4731-10 1/10W 47kΩ
R344 117-1531-10 1/10W 15kΩ
R345 117-1221-10 1/10W 1.2kΩ
R346 117-3941-10 1/10W 390kΩ
R347 117-2031-10 1/10W 20kΩ
R348 111-4791-91 1/4WS 4.7Ω
R401 117-1531-10 1/10W 15kΩ
R402 032-0092-21 1/10W 3.3kΩ±1%
R403 032-0092-21 1/10W 3.3kΩ±1%
R404 032-0139-50 1/10W 4.7kΩ
R405 032-0139-50 1/10W 4.7kΩ
R406 117-2721-10 1/10W 2.7kΩ
R407 117-3321-10 1/10W 3.3kΩ
R408 117-2241-10 1/10W 220kΩ
R409 117-4711-10 1/10W 470Ω
R410 117-2241-10 1/10W 220kΩ
R411 117-3321-10 1/10W 3.3kΩ
R412 117-4721-10 1/10W 4.7kΩ
R413 111-4731-91 1/4WS 47kΩ
R414 111-5611-91 1/4WS 560Ω
R415 060-0108-00 1/6ZP 0Ω JW
R417 111-1811-91 1/4WS 180Ω
R418 111-5611-91 1/4WS 560Ω
R420 111-4731-91 1/4WS 47kΩ
R421 111-4731-91 1/4WS 47kΩ
R422 111-5611-91 1/4WS 560Ω
R423 111-1811-91 1/4WS 180Ω
R425 111-2721-91 1/4WS 2.7kΩ
R426 111-5611-91 1/4WS 560Ω
R428 111-4731-91 1/4WS 47kΩ
R429 111-4731-91 1/4WS 47kΩ
R430 111-5611-91 1/4WS 560Ω
R431 111-1031-91 1/4WS 10kΩ
R436 111-4731-91 1/4WS 47kΩ
R437 117-4731-10 1/10W 47kΩ
R438 117-2221-10 1/10W 2.2kΩ
R439 117-4731-10 1/10W 47kΩ
R440 117-1051-10 1/10W 1MΩ
R441 117-1051-10 1/10W 1MΩ
R442 117-1021-10 1/10W 1kΩ
R443 117-4731-10 1/10W 47kΩ
R444 117-1531-10 1/10W 15kΩ
R445 117-1221-10 1/10W 1.2kΩ
R446 117-3941-10 1/10W 390kΩ
R447 117-2031-10 1/10W 20kΩ
R448 111-4791-91 1/4WS 4.7Ω
R501 117-3931-10 1/10W 39kΩ
R502 117-3931-10 1/10W 39kΩ
R503 117-3931-10 1/10W 39kΩ
R504 117-3931-10 1/10W 39kΩ
R505 117-3921-10 1/10W 3.9kΩ
R506 117-2731-10 1/10W 27kΩ
R507 117-3921-10 1/10W 3.9kΩ
R508 117-2731-10 1/10W 27kΩ
R509 117-2231-10 1/10W 22kΩ
R510 117-6831-10 1/10W 68kΩ
R511 117-2721-10 1/10W 2.7kΩ
R512 117-2241-10 1/10W 220kΩ
R513 117-2721-10 1/10W 2.7kΩ
R514 117-2241-10 1/10W 220kΩ
R515 117-1051-10 1/10W 1MΩ
R516 117-4711-10 1/10W 470Ω
R517 117-1051-10 1/10W 1MΩ
R518 117-1021-10 1/10W 1kΩ
R519 117-1231-10 1/10W 12kΩ
R520 117-4731-10 1/10W 47kΩ
R521 117-4731-10 1/10W 47kΩ
R522 117-1531-10 1/10W 15kΩ
R523 117-1221-10 1/10W 1.2kΩ
R524 117-3941-10 1/10W 390kΩ
R525 117-2031-10 1/10W 20kΩ
R526 111-4791-91 1/4WS 4.7Ω
R602 117-4711-10 1/10W 470Ω
R603 117-1231-10 1/10W 12kΩ
R604 117-1031-10 1/10W 10kΩ
R605 117-1031-10 1/10W 10kΩ
R606 117-1031-10 1/10W 10kΩ
R607 117-1031-10 1/10W 10kΩ
R608 117-1031-10 1/10W 10kΩ
R609 117-1031-10 1/10W 10kΩ
R610 117-4721-10 1/10W 4.7kΩ
R611 117-3321-10 1/10W 3.3kΩ
R612 117-4721-10 1/10W 4.7kΩ
R613 117-4721-10 1/10W 4.7kΩ
R614 117-1541-10 1/10W 150kΩ
R615 117-2231-10 1/10W 22kΩ
R616 117-3321-10 1/10W 3.3kΩ
R617 117-1031-10 1/10W 10kΩ
R618 117-2431-10 1/10W 24kΩ
R619 117-1031-10 1/10W 10kΩ
R620 111-2221-91 1/4WS 2.2kΩ
R621 117-1031-10 1/10W 10kΩ
R622 032-0087-66 1/4WS 6.8kΩ±1%
R623 117-4721-10 1/10W 4.7kΩ
R624 111-2201-91 1/4WS 22Ω
R625 117-1231-10 1/10W 12kΩ
R626 117-4721-10 1/10W 4.7kΩ
R627 117-1011-10 1/10W 100Ω
R628 117-1011-10 1/10W 100Ω
R629 117-2221-10 1/10W 2.2kΩ
R630 117-2221-10 1/10W 2.2kΩ
