Clarion EF-1080I-C User Manual

- 4 -
EF-1080I-C
■ELECTRICAL PARTS LIST
Main PWB(B1) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
C101 176-2201-00 22pF CH
C102 176-4711-00 470pF CH
C103 182-1043-63 50V0.1μF
C104 172-1851-11 50V1.8μF
C105 172-1541-11 0.15μF
C106 172-1831-11 0.018μF
C107 173-1221-11 1200pF J
C108 172-3931-11 0.039μF
C109 172-4731-11 0.047μF
C110 173-8221-11 8200pF J
C111 173-6821-11 6800pF J
C112 172-1841-15 0.18μF
C113 172-5631-11 0.056μF
C114 172-3931-11 0.039μF
C115 172-1231-11 0.012μF
C116 042-0555-66 16V10μF
C117 176-8097-00 8pF CH
C118 183-6853-59 35V6.8μF
C119 184-4763-51 35V47μF
C120 172-1041-11 0.1μF
C121 042-0555-66 16V10μF
C122 042-0555-66 16V10μF
C201 176-2201-00 22pF CH
C202 176-4711-00 470pF CH
C203 182-1043-63 50V0.1μF
C204 172-1541-11 0.15μF
C205 172-1851-11 50V1.8μF
C206 173-1221-11 1200pF J
C207 172-1831-11 0.018μF
C208 172-4731-11 0.047μF
C209 172-3931-11 0.039μF
C210 173-6821-11 6800pF J
C211 173-8221-11 8200pF J
C212 172-5631-11 0.056μF
C213 172-1841-15 0.18μF
C214 172-1231-11 0.012μF
C215 172-3931-11 0.039μF
C216 042-0555-66 16V10μF
C217 176-8097-00 8pF CH
C218 183-6853-59 35V6.8μF
C219 184-4763-51 35V47μF
C220 172-1041-11 0.1μF
C221 042-0555-66 16V10μF
C222 042-0555-66 16V10μF
C301 176-2201-00 22pF CH
C302 176-4711-00 470pF CH
C303 182-1043-63 50V0.1μF
C304 172-4731-11 0.047μF
C305 173-8221-11 8200pF J
C306 172-1541-11 0.15μF
C307 173-2221-11 2200pF J
C308 172-1851-11 50V1.8μF
C309 172-2731-11 0.027μF
C310 172-1041-11 0.1μF
C311 172-4731-11 0.047μF
C312 172-1031-11 0.01μF
C313 173-1821-11 1800pF J
C316 042-0555-66 16V10μF
C317 176-8097-00 8pF CH
C318 182-2253-63 50V2.2μF
C319 184-4763-51 35V47μF
C320 172-1041-11 0.1μF
C321 042-0555-66 16V10μF
C322 042-0555-66 16V10μF
C401 176-2201-00 22pF CH
C402 176-4711-00 470pF CH
C403 051-2024-00 TDA7295
C403 182-1043-63 50V0.1μF
C404 173-8221-11 8200pF J
C405 172-4731-11 0.047μF
C406 173-2221-11 2200pF J
C407 172-1541-11 0.15μF
C408 172-2731-11 0.027μF
C409 172-1851-11 50V1.8μF
C410 172-4731-11 0.047μF
C411 172-1041-11 0.1μF
C412 173-1821-11 1800pF J
C413 172-1031-11 0.01μF
C416 042-0555-66 16V10μF
C417 176-8097-00 8pF CH
C418 182-2253-63 50V2.2μF
C419 184-4763-51 35V47μF
C420 172-1041-11 0.1μF
C421 042-0555-66 16V10μF
C422 042-0555-66 16V10μF
C501 172-2231-11 0.022μF
C502 176-4701-00 47pF CH
C503 172-2241-11 0.22μF
C504 172-2241-11 0.22μF
C505 042-0555-66 16V10μF
C506 042-0555-66 16V10μF
C507 176-1007-00 10pF CH
C508 176-4711-00 470pF CH
C509 182-2253-63 50V2.2μF
C510 182-1063-52 35V10μF
C511 184-4763-51 35V47μF
C512 172-1041-11 0.1μF
C513 176-1011-00 100pF CH
C514 176-1011-00 100pF CH
C534 042-9024-00 16V470μF
C537 042-9024-00 16V470μF
C538 042-9024-00 16V470μF
C590 042-9023-00 35V330μF
C591 042-0505-00 25V1μF
C601 172-6841-11 0.68μF
C602 178-1042-78 0.1μF
C603 184-4773-11 6.3V470μF
C604 042-9020-00 16V2200μF
C605 178-8232-78 0.082μF
C606 172-1041-11 0.1μF
C607 182-4763-33 16V47μF
C608 182-1053-63 50V1μF
C609 178-1032-78 0.01μF
C610 182-2263-33 16V22μF
C611 182-1053-63 50V1μF
C612 178-1042-78 0.1μF
C613 173-1521-11 1500pF J
C614 042-0555-66 16V10μF
C615 178-1042-78 0.1μF
C616 178-1042-78 0.1μF
C617 178-1032-78 0.01μF
C620 173-2221-11 2200pF J
C621 042-9014-00 35V2200μＦ
C622 042-9014-00 35V2200μＦ
C623 172-1041-11 0.1μF
C624 172-1041-11 0.1μF
C625 184-4763-51 35V47μF
C626 184-4763-51 35V47μF
C627 172-1041-11 0.1μF
C628 172-1041-11 0.1μF
C629 172-1041-11 0.1μF
C630 172-1041-11 0.1μF
C631 184-2273-32 16V220μF
C632 184-2273-32 16V220μF
C633 042-9024-00 16V470μF
C635 172-1041-11 0.1μF
C636 172-1041-11 0.1μF
C639 172-1041-11 0.1μF
C640 172-1041-11 0.1μF
C641 172-1041-11 0.1μF
C642 172-1041-11 0.1μF
C643 172-1041-11 0.1μF
C644 042-9020-00 16V2200μF
C645 042-9023-00 35V330μF
C646 042-9023-00 35V330μF
D601 001-0592-00 RM4Z
D602 001-0330-00 1SS119
D603 001-0330-00 1SS119
D604 001-0425-20 HZS6.2
D605 001-0650-0A FMG22R
D606 001-0650-0B FMG22S
D607 001-0425-20 HZS6.2
D608 001-0466-00 S5688B
D609 001-0466-00 S5688B
IC101 051-3001-00 NJM4580D
IC102 051-3001-00 NJM4580D
IC103 051-3021-00 NJM4741D
IC104 051-3021-00 NJM4741D
IC105 051-3021-00 NJM4741D
IC106 051-0422-51 NJM4558D
IC201 051-3001-00 NJM4580D
IC202 051-3001-00 NJM4580D
IC203 051-3021-00 NJM4741D
IC204 051-3021-00 NJM4741D
IC205 051-3021-00 NJM4741D
IC206 051-0422-51 NJM4558D
IC301 051-3001-00 NJM4580D
IC302 051-3001-00 NJM4580D
IC401 051-2024-00 TDA7295
IC402 051-2024-00 TDA7295
IC404 051-2024-00 TDA7295
IC405 051-2024-00 TDA7295
IC601 051-5817-00 TL594CN
IC602 051-1160-00 NJM7815FA
IC603 051-1306-00 NJM7915FA
J101 074-1137-00 13P DIN
J102 074-0973-00 14P
L601 010-8018-00 COIL
L602 010-8018-00 COIL
Q101 102-2712-00 2SC2712
Q102 125-8008-00 PN4392
Q103 100-1298-00 2SA1298
Q104 100-1298-00 2SA1298
Q201 102-2712-00 2SC2712
Q202 125-8008-00 PN4392
Q203 100-1298-00 2SA1298
Q204 100-1298-00 2SA1298
Q301 102-2712-00 2SC2712
Q302 125-8008-00 PN4392
Q303 100-1298-00 2SA1298
Q304 100-1298-00 2SA1298
Q401 102-2712-00 2SC2712
Q402 125-8008-00 PN4392
Q403 100-1298-00 2SA1298
Q404 100-1298-00 2SA1298
Q501 100-1298-00 2SA1298
Q502 100-1298-00 2SA1298
Q503 125-8008-00 PN4392
Q504 102-2712-00 2SC2712
Q601 100-1298-00 2SA1298
Q602 102-2712-00 2SC2712
Q603 102-2712-00 2SC2712
Q604 102-2712-00 2SC2712
Q605 100-1431-00 2SA1431
Q606 102-2712-00 2SC2712
Q607 100-1298-00 2SA1298
Q608 100-1298-00 2SA1298
Q609 102-2712-00 2SC2712
Q610 102-2712-00 2SC2712
Q611 100-1298-00 2SA1298
Q612 125-8004-00 MTAJ30N06HD
Q613 125-8004-00 MTAJ30N06HD
Q614 125-8004-00 MTAJ30N06HD
