FZ104PAE
9
FM Tuner
Frequency Range: 87.9 - 107.9MHz
Usable Sensitivity: Less than 10dB at S/N 30dB
Stereo Separation: >30dB(1kHz)
Signal/noise ratio: >55dB
AM Tuner
Frequency Range: 530 - 1710KHz
Usable Sensitivity: Less th an 40dB
USB
USB Host: Host 1.1 compatibles 2.0
MP3/WMA mode
MP3 sampling rate: 32kHz, 44.1kHz, 48kHz
MP3 bit rate: 8~320kbps and variable bit
rate
WMA bit rate: 8~320kbps
Logical format: ISO9660, Joliet
Number of file: Maximum 999
Max directory 10
depth:
Sorting Method: Tree sorting
Max File/Directory 64Byte
Name:
ID3 tag: V2.0 or later
General
Power Supply Voltage: 14.4V DC (10.8 to
15.6V), Negative Ground
Fuse: 15A
Speaker Impedance: 4-8 ohms per channel
Power output: 50W x 4 channels
Aux-in level: ≥ 650mV
Note: Specifications and design are subject to
change without notice for further improvement.
Power Output:
20W × 4 Channels at 4 Ω
and 1% THD+N
Signal to Noise Ratio:
74dB (reference: LPF 1 W into 4 Ω)
7. SPECIFICATIONS
English
Owner’s Manual
Operation Temperature: -20ºc to +70ºc
To Next Page
