- 8 -PP-2515L
C506 166-2201-50 22pF CH
C507 168-1042-78 16V 0.1uF
C508 166-2201-50 22pF CH
C509 166-2201-50 22pF CH
C510 168-6822-55 6800pF
C511 168-6822-55 6800pF
C512 166-2201-50 22pF CH
C513 166-2201-50 22pF CH
C514 168-1042-78 16V 0.1uF
C515 166-2201-50 22pF CH
C516 166-2201-50 22pF CH
C529 178-1042-78 0.1uF
C530 178-1042-78 0.1uF
C531 178-1842-78 0.18uF
C532 178-1842-78 0.18uF
C533 178-1842-78 0.18uF
C534 178-1842-78 0.18uF
C535 178-8232-78 0.082uF
C536 178-8232-78 0.082uF
C537 166-2201-50 22pF CH
C538 166-2201-50 22pF CH
C539 166-2201-50 22pF CH
C540 166-2201-50 22pF CH
C541 166-2201-50 22pF CH
C542 166-2201-50 22pF CH
C545 178-8222-78 8200pF
C546 178-8222-78 8200pF
C549 178-3932-78 0.039uF
C550 178-3932-78 0.039uF
C553 178-5632-78 0.056uF
C554 178-5632-78 0.056uF
C555 178-6832-78 0.068uF
C556 178-6832-78 0.068uF
C557 178-5632-78 0.056uF
C558 178-6832-78 0.068uF
C559 166-2201-50 22pF CH
C560 166-2201-50 22pF CH
C561 166-2201-50 22pF CH
C562 166-2201-50 22pF CH
C563 178-5632-78 0.056uF
C564 178-6832-78 0.068uF
C565 168-1032-55 0.01uF
C566 168-2232-55 0.022uF
C567 168-1032-55 0.01uF
C568 178-3932-78 0.039uF
C569 178-3932-78 0.039uF
C570 178-3932-78 0.039F
C571 178-3932-78 0.039uF
C572 168-1822-55 1800pF
C573 182-1053-69 50V1uF
C574 182-1063-39 16V10uF
C577 178-1052-78 1uF
C578 178-1052-78 1uF
C579 178-1052-78 1uF
C580 178-1052-78 1uF
C581 168-1822-55 1800pF
C582 183-1053-69 50V1uF
C584 166-2201-50 22pF CH
C585 166-2201-50 22pF CH
C586 166-2201-50 22pF CH
C587 166-2201-50 22pF CH
C599 184-4773-19 6.3V470uF
C601 183-4753-69 50V4.7uF
C602 183-4753-69 50V4.7uF
C701 172-1041-15 0.1uF
C702 042-0447-00 16V2200uF
C703 168-2222-55 2200pF
C704 168-2222-55 2200pF
C705 168-2222-55 2200pF
C706 168-2222-55 2200pF
C707 168-2222-55 2200pF
C708 168-2222-55 2200pF
C709 168-2222-55 2200pF
C710 168-2222-55 2200pF
C711 168-2222-55 2200pF
C712 172-1041-15 0.1uF
C713 182-1063-39 16V10uF
C714 183-6843-69 50V0.68uF
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C802 182-4763-39 16V47uF
C803 182-1063-39 16V10uF
C804 182-4763-19 6.3V47uF
C805 182-4763-19 6.3V47uF
C806 182-1063-39 16V10uF
C807 182-1063-39 16V10uF
C901 168-1042-78 16V 0.1uF
C902 182-1063-39 16V10uF
C903 183-4753-69 50V4.7uF
C904 183-1053-69 50V1uF
C905 166-4711-50 470pF CH
C906 166-4711-50 470pF CH
C907 168-1042-78 16V 0.1uF
C910 166-1021-50 1000pF CH
C911 182-1073-39 16V100uF
CCT205 050-0140-54 1/32W 1k ohmx4J
CCT206 050-0140-54 1/32W 1k ohmx4J
CCT207 050-0140-54 1/32W 1k ohmx4J
CCT209 050-0140-54 1/32W 1k ohmx4J
CCT210 050-0140-54 1/32W 1k ohmx4J
D401 001-0422-38 MTZJ36
D402 001-0589-91 1SS145
D403 001-0589-91 1SS145
D404 001-0347-44 MA4082M
D404 001-0346-45 MTZJ8.2C
D404 001-0401-44 HZS9 A2
D601 001-0516-90 MA111
D701 001-2015-00 RL253
D702 001-0466-90 S5688B
D703 001-0347-34 MA4062L
D703 001-0346-34 MTZJ6.2A
D703 001-0401-34 HZS6 C1
D704 001-0466-90 S5688B
D802 001-0347-48 MA4091H
D802 001-0346-49 MTZJ10A
D802 001-0401-48 HZS9 C2
D803 001-0516-90 MA111
D804 001-0504-31 HZS6 A2L
D805 001-0516-90 MA111
D806 001-0504-31 HZS6 A2L
D808 001-0504-45 HZS9B1L
D902 001-0504-48 HZS9C2L
D903 001-0516-90 MA111
IC201 052-1173-20 uPD178078GF-568-
3BA
IC301 051-3034-90 NJM4558V
IC302 051-5027-00 LC75412WH
IC501 051-3019-90 NJM2060V
IC503 051-3019-90 NJM2060V
IC504 051-3019-90 NJM2060V
IC505 051-3019-90 NJM2060V
IC506 051-2042-00 TA8275H
J201 074-1191-26 26P
J701 074-1068-11 NS10+6
L104 010-2003-04 COIL
L202 010-6009-64 2.2uH
L701 009-0670-01 CHOKE
L701 009-0670-81 CHOKE
P701 076-0540-14 14P
Q104 192-2458-51 2SC2458Y.GR.BL
Q105 192-2458-51 2SC2458Y.GR.BL
Q106 190-1150-00 2SA1150
Q107 125-2004-92 RN1402
Q107 125-2005-91 UN2211TX
Q107 125-2020-92 DTC114EK
Q107 125-2031-92 MUN2211
Q108 190-1150-00 2SA1150
Q201 125-2004-92 RN1402
Q201 125-2005-91 UN2211TX
Q201 125-2020-92 DTC114EK
Q201 125-2031-92 MUN2211
Q301 125-2004-92 RN1402
Q301 125-2005-91 UN2211TX
Q301 125-2020-92 DTC114EK
Q301 125-2031-92 MUN2211
Q302 125-2004-92 RN1402
Q302 125-2005-91 UN2211TX
Q302 125-2020-92 DTC114EK
Q302 125-2031-92 MUN2211
Q303 191-0709-00 2SB709A-Q.R.S
Q303 190-1037-00 2SA1037
Q303 190-1162-00 2SA1162
Q401 192-2712-00 2SC2712
Q401 192-2412-00 2SC2412
Q401 193-0601-00 2SD601
Q402 125-9006-90 IMX1
Q402 125-9007-90 HN1C01F
Q403 125-2004-92 RN1402
Q403 125-2005-91 UN2211TX
Q403 125-2020-92 DTC114EK
Q403 125-2031-92 MUN2211
Q404 125-0002-92 RN2402
Q404 125-0001-91 UN2111TX
Q404 125-0014-92 DTA114EK
Q501 125-4001-90 XN1504
Q502 125-4001-90 XN1504
Q503 125-0006-90 UN2110
Q504 125-0002-92 RN2402
Q504 125-0001-91 UN2111TX
Q504 125-0014-92 DTA114EK
Q505 125-0002-92 RN2402
Q505 125-0001-91 UN2111TX
Q505 125-0014-92 DTA114EK
Q506 125-0006-90 UN2110
Q701 192-2712-00 2SC2712
Q701 192-2412-00 2SC2412
Q701 193-0601-00 2SD601
Q801 193-2118-00 2SD2118
Q802 125-2004-92 RN1402
Q802 125-2005-91 UN2211TX
Q802 125-2020-92 DTC114EK
Q802 125-2031-92 MUN2211
Q803 190-1150-00 2SA1150
Q804 125-2004-92 RN1402
Q804 125-2005-91 UN2211TX
Q804 125-2020-92 DTC114EK
Q804 125-2031-92 MUN2211
Q805 125-0002-92 RN2402
Q805 125-0001-91 UN2111TX
Q805 125-0014-92 DTA114EK
Q806 193-1858-00 2SD1858
Q808 125-2004-92 RN1402
Q808 125-2005-91 UN2211TX
Q808 125-2020-92 DTC114EK
Q808 125-2031-92 MUN2211
Q809 191-0709-00 2SB709A-Q.R.S
Q809 190-1037-00 2SA1037
Q809 190-1162-00 2SA1162
Q810 191-1205-60 2SB1205RST
Q811 193-2118-00 2SD2118
Q812 125-9003-92 IMD3
Q812 125-9002-92 RN4602
Q813 103-2012-00 2SD2012
Q903 103-2012-00 2SD2012
Q904 125-2004-92 RN1402
Q904 125-2005-91 UN2211TX
Q904 125-2020-92 DTC114EK
Q904 125-2031-92 MUN2211
Q905 190-1298-00 2SA1298
Q906 125-2004-92 RN1402
Q906 125-2005-91 UN2211TX
Q906 125-2020-92 DTC114EK
Q906 125-2031-92 MUN2211
Q907 125-2004-92 RN1402
Q907 125-2005-91 UN2211TX
Q907 125-2020-92 DTC114EK
Q907 125-2031-92 MUN2211
R111 119-2221-15 1/16W 2.2k ohm
R112 119-4721-15 1/16W 4.7k ohm
R113 119-1021-15 1/16W 1k ohm
R114 111-4701-98 1/4W 47 ohm
R115 119-2221-15 1/16W 2.2k ohm
R116 111-1501-98 1/4W 15 ohm
R117 119-1021-15 1/16W 1k ohm
R118 119-4741-15 1/16W 470k ohm
R119 111-1001-98 1/4W 10 ohm
