Clarion PP-2515L User Manual

- 7 -
PP-2515L
20 621-0603-25 LOCK ARM R 1
21 621-0604-22 GEAR BASE 1
22 621-0605-22 GEAR COVER 1
23 621-0606-21 IDLE CASE 1
24 816-2590-00 VINYL COAT WIRE(GRN) 1
25 621-0608-21 SECOND GEAR 1
26 621-0609-20 BASE GEAR 1
27 621-0610-20 IDLE GEAR A 1
28 621-0611-20 IDLE GEAR B 1
29 621-0612-21 ROLLER GEAR A 1
30 621-0613-20 ROLLER GEAR B 1
31 621-0614-20 ROLLER GEAR C 1
32 621-0615-21 ROLLER GEAR D 1
33 621-0616-20 POWER GEAR A 1
34 621-0617-20 POWER GEAR B 1
35 621-0618-20 POWER GEAR C 1
36 621-0619-20 POWER GEAR D 1
37 621-0620-20 THREAD GEAR A 1
38 621-0621-20 THREAD GEAR B 1
39 621-0622-21 ROLLER SLEEVE 2
40 621-0623-22 LS-HOLDER 1
41 621-0624-22 GUIDE RAIL 1
42 816-2593-00 LEAD WIRE(PUR) 1
43 816-2542-01 FLAT WIRE(10P) 1
44 716-3473-00 SCREW 2
45 621-0709-20 SH-BASE 1
46 621-0629-20 LOADING ROLLER 2
47 345-8704-20 CUSHION RUBBER 1
48 622-1571-21 ROLLER SHAFT 1
49 624-0018-01 LEAD SCREW 1
50 629-0081-20 DAMPER F 2
51 629-0082-20 DAMPER R 1
52 714-2003-81 MACHINE SCREW 2
53 716-1507-00 SCREW 9
54 716-1733-00 SCREW 2
55 716-3469-00 SCREW 2
56 716-3446-00 SCREW 2
57 750-3465-21 ROLLER SPRING L 1
58 750-3466-20 ROLLER SPRING R 1
59 750-3467-21 SHIFT SPRING 1
60 750-3468-20 RACK SPRING 1
61 750-3469-20 CLAMPER SPRING 1
62 750-3470-20 ID-LOCK SPRING 1
63 816-2592-00 LEAD WIRE(BLU) 1
64 750-3472-21 DR-SPRING F 2
65 750-3473-20 DR-SPRING RA 1
66 750-3474-20 DR-SPRING RB 1
67 750-3475-21 DR-SPRING C 1
68 620-1023-23 CLAMPER PLATE 1
69 620-1024-23 SENSOR ARM 1
70 621-0708-20 CLAMPER RING 1
71 621-0626-21 STOPPER LINK 1
72 621-0627-21 DISC STOPPER 1
73 750-3471-20 SENSOR SPRING 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
■ELECTRICAL PARTS LIST
Main PWB(B1) section
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
BL101 880-1917E FM/AM TUNER
C104 119-0000-05 1/16W 0 ohm JW
C105 166-1511-50 150pF CH
C114 166-1007-50 10pF CH
C116 168-1042-78 16V 0.1uF
C118 168-1022-55 1000pF
C119 182-1073-29 10V100uF
C120 042-0458-93 50V2.2uF
C122 182-1073-29 10V100uF
C123 182-1073-29 10V100uF
C125 182-4763-39 16V47uF
C126 178-1052-78 1uF
C127 168-1532-55 0.015uF
C128 168-3932-78 0.039uF
C129 168-3932-78 0.039μF
C130 166-1201-50 12pF CH
C132 166-2201-50 22pF CH
C133 166-1501-50 15pF CH
C134 168-1022-55 1000pF
C135 168-1042-78 16V 0.1uF
C136 168-1042-78 16V 0.1uF
C137 168-1042-78 16V 0.1uF
C138 168-1042-78 16V 0.1uF
C139 166-5601-50 56pF CH
C201 168-1022-55 1000pF
C202 168-1022-55 1000pF
C203 166-1011-50 100pF CH
C204 166-1011-50 100pF CH
C205 166-1011-50 100pF CH
C206 166-1011-50 100pF CH
C207 168-1042-78 16V 0.1uF
C208 168-1042-78 16V 0.1uF
C212 166-8097-50 8pF CH
C213 183-4763-39 16V47uF
C214 168-1042-78 16V 0.1uF
C215 183-4763-39 16V47uF
C216 168-1042-78 16V 0.1uF
C217 042-0403-55 16V33uF
C218 042-0403-55 16V33uF
C219 168-1042-78 16V 0.1uF
C301 168-4722-55 4700pF
C302 168-1042-78 16V 0.1uF
C303 182-4763-39 16V47uF
C304 166-1011-50 100pF CH
C305 168-1042-78 16V 0.1uF
C306 184-2273-29 10V220uF
C307 182-1063-39 16V10uF
C308 166-1011-50 100pF CH
C309 183-1066-38 16V10uF NP
C310 183-1066-38 16V10uF NP
C315 182-2263-19 6.3V22uF
C316 182-1053-69 50V1uF
C318 178-1042-78 0.1uF
C319 178-1042-78 0.1uF
C321 182-1053-69 50V1uF
C322 178-4742-78 0.47uF
C323 178-4742-78 0.47uF
C324 168-1222-55 1200pF
C325 182-1053-69 50V1uF
C326 182-1053-69 50V1uF
C327 168-1222-55 1200pF
C328 182-1063-39 16V10uF
C329 182-1063-39 16V10uF
C330 182-1063-39 16V10uF
C331 182-1063-39 16V10uF
C332 178-1842-78 0.18uF
C333 178-1842-78 0.18uF
C334 178-1842-78 0.18uF
C335 178-1842-78 0.18uF
C336 168-8212-55 820pF
C337 168-8212-55 820pF
C338 168-8212-55 820pF
C339 168-8212-55 820pF
C340 182-1063-39 16V10uF
C341 182-1063-39 16V10uF
C342 168-1832-55 0.018uF
C343 182-1063-39 16V10uF
C344 182-1063-39 16V10uF
C345 182-1063-39 16V10uF
C346 182-1063-39 16V10uF
C405 168-1022-55 1000pF
C406 168-1022-55 1000pF
C407 168-1022-55 1000pF
C408 168-2232-55 0.022uF
C409 182-1063-39 16V10uF
C410 182-1063-39 16V10uF
C411 182-1063-39 16V10uF
C412 182-1063-39 16V10uF
C501 168-2222-55 2200pF
C502 168-2712-55 270pF
C503 168-2222-55 2200pF
C504 168-2712-55 270pF
C505 166-2201-50 22pF CH
