PU-2471A
PU-2472B, C
- 9 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R810 119-2231-15 1/10W 22k ohm
R811 119-1031-15 1/10W 10k ohm
R812 119-1031-15 1/10W 10k ohm
R813 119-1031-15 1/10W 10k ohm
R815 119-1031-15 1/10W 10k ohm
R819 119-1031-15 1/10W 10k ohm
R820 119-1031-15 1/10W 10k ohm
R821 119-1031-15 1/10W 10k ohm
R822 119-1031-15 1/10W 10k ohm
R824 119-1231-15 1/10W 12k ohm
SUP1 060-0122-91 DSP-141N-S00B
TH501 002-0303-90 6.8 ohm
X100 061-3013-90 4.332MHz
X401 061-3031-90 4.000MHz
X801 061-1081-90 12MHz
Switch PWB section(B2) : PU-2471A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D1 001-7053-90 FA1111R-22(A-G)
D1 001-7053-91 BG1111R-760(A-H)
D2 001-7053-90 FA1111R-22(A-G)
D2 001-7053-91 BG1111R-760(A-H)
D3 001-7053-90 FA1111R-22(A-G)
D3 001-7053-91 BG1111R-760(A-H)
D4 001-7053-90 FA1111R-22(A-G)
D4 001-7053-91 BG1111R-760(A-H)
D5 001-7053-90 FA1111R-22(A-G)
D5 001-7053-91 BG1111R-760(A-H)
D6 001-7053-90 FA1111R-22(A-G)
D6 001-7053-91 BG1111R-760(A-H)
D7 001-7053-90 FA1111R-22(A-G)
D7 001-7053-91 BG1111R-760(A-H)
D8 001-7053-90 FA1111R-22(A-G)
D8 001-7053-91 BG1111R-760(A-H)
D9 001-7053-90 FA1111R-22(A-G)
D9 001-7053-91 BG1111R-760(A-H)
D10 001-7053-90 FA1111R-22(A-G)
D10 001-7053-91 BG1111R-760(A-H)
D11 001-7053-90 FA1111R-22(A-G)
D11 001-7053-91 BG1111R-760(A-H)
D12 001-7053-90 FA1111R-22(A-G)
D12 001-7053-91 BG1111R-760(A-H)
D13 001-7053-90 FA1111R-22(A-G)
D13 001-7053-91 BG1111R-760(A-H)
D14 001-7053-90 FA1111R-22(A-G)
D14 001-7053-91 BG1111R-760(A-H)
D15 001-7053-90 FA1111R-22(A-G)
D15 001-7053-91 BG1111R-760(A-H)
D16 001-7053-90 FA1111R-22(A-G)
D16 001-7053-91 BG1111R-760(A-H)
D17 001-7053-90 FA1111R-22(A-G)
D17 001-7053-91 BG1111R-760(A-H)
D18 001-7053-90 FA1111R-22(A-G)
D18 001-7053-91 BG1111R-760(A-H)
D19 001-7053-90 FA1111R-22(A-G)
D19 001-7053-91 BG1111R-760(A-H)
D20 001-7053-90 FA1111R-22(A-G)
D20 001-7053-91 BG1111R-760(A-H)
D21 001-7053-90 FA1111R-22(A-G)
D21 001-7053-91 BG1111R-760(A-H)
D22 001-7053-90 FA1111R-22(A-G)
D22 001-7053-91 BG1111R-760(A-H)
P101 074-1304-68 18P
R4 116-5611-15 1/4W 560 ohm
R5 116-5611-15 1/4W 560 ohm
(A-H)
R6 116-5611-15 1/4W 560 ohm
R7 116-5611-15 1/4W 560 ohm
(A-H)
R8 116-5611-15 1/4W 560 ohm
R9 116-5611-15 1/4W 560 ohm
(A-H)
R10 116-5611-15 1/4W 560 ohm
R11 116-5611-15 1/4W 560 ohm
(A-H)
R12 116-5611-15 1/4W 560 ohm
R13 116-5611-15 1/4W 560 ohm
(A-H)
R14 117-0000-05 1/8W 0 ohm JW
R15 117-1221-15 1/8W 1.2k ohm
(A-G)
R15 117-1521-15 1/8W 1.5k ohm
(A-H)
Switch PWB section(B2) : PU-2472B,C
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
J101 074-1228-68 18P
PL101 017-0454-02 14V40mA
PL102 017-0454-02 14V40mA
PL103 017-0454-02 14V40mA
PL104 017-0454-02 14V40mA
PL105 017-0454-02 14V40mA
S101 013-3741-11 SKQCAE
S102 013-3741-11 SKQCAE
S103 013-3741-11 SKQCAE
S104 013-3741-11 SKQCAE
S105 013-3741-11 SKQCAE
S106 013-3741-11 SKQCAE
S107 013-3741-11 SKQCAE
S108 013-3741-11 SKQCAE
S109 013-3741-11 SKQCAE
S110 013-3741-11 SKQCAE
S111 013-3741-11 SKQCAE
S112 013-3741-11 SKQCAE
S113 013-3741-11 SKQCAE
S114 013-3741-11 SKQCAE
S115 013-3741-11 SKQCAE
S116 013-3741-11 SKQCAE
S117 013-3741-11 SKQCAE
S118 013-3741-11 SKQCAE
VR101 016-0010-16 VR
ISO PWB section(B3)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D1 001-0334-30 RL202
F1 060-0057-56 AUTO FUSE 10A
J1 074-1159-01 ISO CONNECTOR
P1 076-0324-10 10P
P2 076-0324-15 15P
R1 032-0140-50 1/8W 10k ohm F
R2 032-0140-50 1/8W 10k ohm F
R3 032-0140-50 1/8W 10k ohm F
R4 032-0140-50 1/8W 10k ohm F
R5 032-0140-50 1/8W 10k ohm F
R6 032-0140-50 1/8W 10k ohm F
T1 009-9006-60 CHOKE COIL
TH1 002-0314-94 POSISTOR
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
CD PWB section(B4) : CD mechanism
C101 168-1042-78 0.1uF
C102 045-4701-50 47pF
C103 046-4722-58 4700pF
C104 168-1042-78 0.1uF
C105 046-1532-78 0.015uF
C106 046-1032-78 0.01uF
C107 046-1032-78 0.01uF
C108 046-4722-58 4700pF
C109 046-1522-58 1500pF
C110 046-3332-78 0.033uF
C111 168-1042-78 0.1uF
C112 046-3332-78 0.033uF
C113 168-1042-78 0.1uF
C114 168-1042-78 0.1uF
C115 046-4712-58 470pF
C116 046-4712-58 470pF
C117 043-0533-50 0.047uF
C118 043-0533-50 0.047uF
C119 045-2701-50 27pF
C120 045-1801-50 18pF
C121 163-1063-35 16V10uF
C122 178-1052-78 1uF
C123 046-1032-78 0.01uF
C124 163-1073-05 4V100uF
C125 168-1042-78 0.1uF
C126 168-1042-78 0.1uF
C129 178-1052-78 1uF
C201 163-3363-05 4V33uF
C202 168-1042-78 0.1uF
C203 178-1052-78 1uF
C204 163-1073-05 4V100uF
C205 163-3363-05 4V33uF
C206 168-1042-78 0.1uF
C207 043-0533-50 0.047uF
C208 046-6822-58 6800pF
C209 168-1042-78 0.1uF
C210 043-0533-50 0.047uF
C211 168-1042-78 0.1uF
C212 168-1042-78 0.1uF
C213 045-5096-50 5pF
C214 045-5601-50 56pF
C215 043-0533-50 0.047uF
C216 178-1052-78 1uF
C217 045-1011-50 100pF
C301 163-1073-35 16V100uF
C302 168-1042-78 0.1uF
C303 043-0533-50 0.047uF
D201 001-0516-90 MA111
IC101 051-6376-00 TC94A14FA
IC102 051-3279-90 BA033LBSG
IC201 051-5710-90 TA2157F
Note) Some parts depend on each model. The model name is specified in the description.
