Clarion VRX765VD User Manual

Basic Operations
25
VRX765VD
280-8358-00
English
Owner’s manual
Adjusting the balance/fader
Adjusting the BASS
The bass gain, bass frequency (center
frequency) and bass Q can be adjusted as
follows.
Adjusting the MID
The MID gain, MID frequency (center frequency)
and MID Q can be adjusted as follows.
Adjusting the TREBLE
The treble gain and treble frequency (center
frequency) can be adjusted as follows.
Adjusting the non fader output
volume
You can adjust the volume output from the unit’s
non fader output terminal.
2-1. Touch the []] key of the BAL/FAD item.
3-1. Touch the [{] or [}] key to adjust to the
fader level.
* The factory default setting is “0”. (Adjustment
range: front 12 to rear 12)
[{] :
Emphasized the sound from the front
speakers.
[}] :
Emphasized the sound from the rear
speakers.
3-2. Touch the [[] or []] key to adjust to the
balance level.
* The factory default setting is “0”. (Adjustment
range: left 13 to right 13)
[[] :
Emphasized the sound from the left
speakers.
[]] :
Emphasized the sound from the right
speakers.
2-1. Touch the []] key of the BASS item.
3-1. When the AUDIO BASS screen is
displayed, touch the [[] or []] key for the
desirable type to adjust to a desirable level.
GAIN :
–6 to 8 (The factory default setting is “0”.)
FREQ. :
50Hz, 80Hz, 120Hz (The factory default
setting is “50Hz”.)
Q :
1, 1.25, 1.5, 2 (The factory default setting is
“1”.)
2-1. Touch the []] key of the MID item.
3-1. When the AUDIO MID screen is displayed,
touch the [[] or []] key for the desirable type
to adjust to a desirable level.
GAIN :
–6 to 6 (The factory default setting is “0”.)
FREQ. :
700Hz, 1kHz, 2kHz (The factory default
setting is “1kHz”.)
Q :
1.5, 2 (The factory default setting is “2”.)
2-1. Touch the []] key of the TREBLE item.
3-1. When the AUDIO TREBLE screen is
displayed, touch the [[] or []] key for the
desirable type to adjust to a desirable level.
GAIN :
–6 to 6 (The factory default setting is “0”.)
FREQ. :
8kHz, 12kHz (The factory default setting is
“12kHz”.)
2-1/
3-1.
Touch the [[] or []] key of the NON FADER
VOL item to adjust to desirable level.
Setting range :
–6 to 6 (The factory default setting is “0”.)
