16. HDMI MODE
Wire
Connection
of HDMI
can be connected by using the connector cable supplied with
and HDMI cable (sold in the market)
and digital Av
adapter.
(
1) Connection with the iPhone 4 and iPhone 4s
VX404
iPhone 4 and iPhone 4S
Android phone
Apple Genuine
30
pin-Digital AV adapter
(3) Connection with the Android phone
VX404
Apple Genuine 30pin cable
M
icro USB cable sold in the market
MHL adaptor sold
in the market
(
2) Connection with the iPhone 5, iPhone 5s and iPhone 5c
VX404
iP
hone 5, iPhone 5s and iPhone 5c
Apple Genuine
L
ightning-Digital AV adapter
Apple Genuine Lightning
TM
cable
H
DMI cable sold in the market
H
DMI cable sold in the market
H
DMI cable sold in the
m
arket
(
4) Connecon with the equipment with HDMI output
VX404
E
lectronic devices with HDMI output
H
DMI cable sold in the
m
arket
iPhone 4, iPhone 4s, iPhone 5, iPhone 5s and iPhone 5c
iPhone 4, iPhone 4s, iPhone 5, iPhone 5s and iPhone 5c
Note:
The following is part of the wiring example.
Depending on the device, there is a case to connect to the device directly with the CCA-771.
Depending on the adapter or device, there is a case that the audio noise and video noise is generated.
