Clarion VX404 - Page 56

55
VX404
English
English
Owner’s Manual
English
Owner’s Manual
Ye llow
Blac
k
Purple
Purple Bla/
ck
Grass-green
Gray
Gray Bla/
ck
White
White Bla/
ck
Green
Green Blac/
k
Blue White/
Orange White/
Red
Brown
Blue
+12Vmainpo
wer
Ground
Rear right +
Rearright -
Parkingbrake cord
Purple Whit/
e
Reverse gear cord
Frontright +
Frontright -
Front left
+
Front left
-
Rear left+
Rear left-
Amplifiertu
r
non cord-
Illumination
+12V accessory
Phone mute
Auto antenna
Note:
*1:
Connecting the PHONE MUTE terminal
It will mute the audio if the lead receives a negative or ground signal.
