UNPACKING
Once the outer cover has been removed, in accordance with the information printed on the
carton, the following items are to be found in styrafoam trays mounted on top of the air-con unit.
1. 2 Metre Outlet Hose
2. Outlet Hose Adapter
3. Hose/Wall Adapter
4. Flat Outlet Adapter
5. Drain Hose
IMPORTANT
The unit has been transported to your dealer in the
upright position. If however, it has subsequently been
laid horizontally, eg. for transportation purposes, then
it MUST be stood in the upright position FOR AT LEAST 6
HOURS BEFORE SWITCHING ON.
INTRODUCTION
As a Dehumidifier or Fan, it may be used in any room or location, with little restriction. As an Air-
conditioner however, an air exhaust outlet is required to be close at hand (within 2 meters using
the hose supplied).
All controls are a pressure pad type, mounted on the front, top of the unit, and are explained
under ‘Functions’ on page 7.
Air flow may be directed, high or low, by moving the louvres, on the front grille, by hand.
CAUTION: Always grip the louvres with both hands, one at either side, to move them up or down.
This is particularly important when the unit is new, and the fitings are tight. Failure to adopt this
procedure could result in damage to the plastic mountings.
Air flow may also be set to sweep, left and right, electronically, from the control panel. this is
explained in ‘Functions’ on page 7.
The noise level of the unit is very low and unobtrusive, and a timer is incorporated so that the unit
can be set to switch itself ON or OFF at predetermined times.
Fig.1
Fig.2
Fig.3
3
