INSTALLATION
REMEMBER - If the unit has been laid on its side for any reason, it MUST be stood in an upright
position for at least 6 hours before switching ON,
• Always ensure that there is an air gap, between a wall and the rear of the unit, of at least
50cm, whatever the mode being used.
• Always locate the unit on a level surface. If located on an incline, or an uneven surface, the
unit could vibrate excessively, resulting in possible component damage.
A. AIR CONDTIONER MODE
When used as an air-conditioner, the hose MUST be connected to the rear air outlet as shown in
fig.2, page 3, via the hose adapter shown in fig.1. The hose adapter simply slides over the runners
either side of the air outlet.
To attach the hose to the hose adapter, enter the leading edge of the wire, bared at the end of
the hose, into one of the grooves on the inside of the adapter. Screw the adapter on to the hose
until it becomes firm, and a good seal is made. The hose is attached to the wall adapter in the
same manner, and the wall adapter should be a good fit into the wall, or window opening.
NOTE: When installing for the first time, attach the hose to the window or wall adapter first, ensuring
the seal is good, then the other end to the outlet adapter, and finally attach the outlet adapter to
the air-con unit as described above.
A flat adapter is also provided, for connection to air ducting or other outlets as required.
B. DEHUMIDIFIER OR FAN MODE
When used in either dehumidifier or fan mode, the unit may be located wherever desired, but
ALWAYS remember to disconnect the hose from the rear of the unit whenever dehumidifier mode
is selected.
HEALTH & SAFETY
It is IMPORTANT that the following health and safety requirements are fully understood by all
those who use or come into contact with the unit.
• DO NOT allow children to play with the unit or tamper with it in any way, eg., by poking
fingers or toys etc. into the front grille .
• DO NOT place articles on top of the unit.
• ALWAYS ensure the air outlet is completely free. DO NOT place clothes or other articles over
the outlet to dry, as any restriction to the air flow will seriously reduce the efficiency of the
unit and ultimately damage the working parts.
• NEVER allow the air flow, in ANY MODE, to be directed on to a sleeping person. This could be
a serious health risk.
• When unplugging the unit, do not yank the plug by the cable.
• Always maintain the unit on a flat, level surface
IMPORTANT:
Always ensure that any ducting or hoses used, are of at least the same cross
sectional area as the supplied hose .
5
