28
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
69 8 mm Flat Washer 106 Spring Pin
70 Brush Spacer 107 ## Guard Plate
71 8 mm Flat Washer 108 6 x 12 mm Socket Head Screw
72 Dust Brush 109 Connecting Block
73 8 x 90 mm Square Head Bolt 110 Connecting Shaft
74 20 x 1.5 mm Nut 111 6 x 8 mm Socket Set Screw
75 Spindle Pulley 112 4.8 x 13 mm X-Head Screw
76 6 x 10 mm Socket Head Bolt 113 10 mm Baffle Ring
77 Draw Handle 114 Needle Bearing
78 ## Dust Draw 115 Bearing Support
79 Steel Ball Spring 116 Finger Knob
80 8 mm Steel Ball 117 5 mm Flat Washer
81 2.9 x 9.5 mm X-head Screw 118 6 x 16 mm Socket Head Screw
82 Ball Fixing Sleeve 119 6mm Flat Washer
83 Microswitch Box Cover 120 Knob
84 Microswitch 121 Guide Block
85 Microswitch Box 122 Bearing Support
86 4 mm Nut 123 Ball Bearing
87 6 x 8 mm Socket Set Screw 124 6 x 16 mm Socket Head Screw
88 Quick Release Cam 125 Door Closing Handle
89 Cam Axis Guide 126 ## Guide Plate
90 20 x 1.5 mm Nut 127 6 mm Locknut
91 Cam Shaft 128 6 x 8 mm Socket Head Screw
92 Quick Release Arm 129 6 mm Flat Washer
93 Quick Release Handle 130 6 x 10 mm Socket Head Screw
94 Tracking Lock Knob 131 Cable Gland
95 Tracking Setting Knob 132 Table Stop Rod
96 Handle Cover 133 8 mm Nut
97 4.8 x 13 mm X-head Screw 134 Fixing Block
98 Locating Plate 135 Lower Blade Guide Plate
99 ## Blade Guard Cover 136 6 x 12 mm Set Screw
100 Spindle 137 6 mm Flat Washer
101 Guide Adjustment Pinion 138 Lower wheel spindle
102 Guide Adjustment Knob 139 6 mm Nut
103 Guide Adjustment Spring 140 6 x 16 mm Set Screw
104 Guide Locking Handle 141 6 mm Nut
105 Rack 142 6 x 8 mm Set Screw
PART NO DESCRIPTION PART NO DESCRIPTION
