PARTS LIST
PART NO DESCRIPTION PART NO DESCRIPTION
1 5 x 12 socket head screw 35 ## Wheel Tread
2 5 mm Washer 36 ## Saw Blade
3 Blade Tension Knob 37 ## Upper Cover Panel
4 ## Blade Tensioner Screw 38 Window Glass
5Spacer 39Window Seal
6 3AMI-15 Circlip 40 4 x 10 X-head Screw
7 ## Frame End cap 41 Microswitch Actuating Clip
8 4 x 25 x-head s/t Screw 42 4 mm Nut
9 8 mm Nut 43 ## Lower Cover Panel
10 Cam 44 6 mm Locknut
11 Tension Coil Spring 45 Closing Spacer
12 Securing Nut 46 6 x 16 mm Socket Head Bolt
13 Pointer Support Plate 47 4 mm Cap Nut
14 Hex head bolt 48 4 mm Flat Washer
15 6 x 12 mm Set Screw 49 LED Worklight Switch
16 6 mm Flat Washer 50 4 x 12 mm Socket Head Screw
17 Stud Bolt 51 4.2 x 9.5 X-head Screw
18 Fixing Block 52 Cable Clamp
19 6 mm Locknut 53 LED Light Switch Box
20 ## Tension Pointer 54 LED Lamp Switch Face Plate
21 Hinge Bolt 55 4 x 12 mm X-head Screw
22 3AMI-8 Circlip 56 Switch
23 Adjusting Block Arbor 57 4 mm toothed Washer
24 Guide Rail Plate 58 4 x 8 mm X-head Screw
25 Tension Guide Block 59 2.9 x 9.5 x-head Screw
26 8 x 16 mm Set Screw 60 Cable Clamp
27 8 mm Flat Washer 61 Cable Clamp
28 8 mm Nut 62 Switch Box
29 Wheel Adjusting Block 63 Terminal Board
30 Upper Wheel Shaft 64 2.9 x 16 mm X-head Screw
31 Ball Bearing 65 Stop /Start Switch
32 3BMI-35 Circlip 66 4 x 12 mm X-head Screw
33 ## Bandsaw Pulley 67 ## Main Frame
34 3AMI-15 Circlip 68 8 mm Domed Nut
