SPECIFICATIONS
CBS300 CBS350
Weight 60.2 kg 76.8 kg
Dimensions (W x D x H) 770 x 575 x 1586 mm 868 x 670 x 1705 mm
Table Size (W x D) 480 x 390 mm 545 x 515 mm
Throat Width 305 mm 340 mm
Table Height from Floor 990 mm 1005
Table tilt angle
0 - 45
o
Mitre Gauge Range
Left 60
o
/ Right 60
o
Maximum Cutting Depth@90
o
165 mm 225 mm
Maximum Cutting Depth@45
o
115 mm 160 mm
Blade Length (welded loop) 2240 mm 2560 mm
Blade Width 12.5 mm
Blade Tooth Pitch 4 tpi
Blade thickness 0.5 mm
Supply Cable Length 2100 mm
Stand Footprint (W x D) 620 x 530 mm 670 x 530 mm
Rated Power @230V 750 W 1100
Blade Speeds 370 or 800 m/min
Duty Cycle S1 continuous
Sound Pressure Level (Lp) 70.7 dB(A)
Sound Power Level Measured (Lw) 83.7 dB(A)
