19
If more than one module is detected, you will be prompted to select
a module before the test.
. Control Module
Engine
Module $A4
Exit
Use the SCROLL button to select a module and press the
ENTER/EXIT button.
2) Wait a few seconds while the code reader validates the PID MAP.
. I/M Readiness
Reading PID.01
-Please Wait-
3) If the vehicle supports both types of tests, then both types show on
the screen for selection
I/M Readiness
Since DTCs Cleared
This Drive Cycle
Exit
4) Use the SCROLL button to view the status of the ‘ MIL’ light
(“ON” or “OFF) and the following monitors:
Misfire monitor—Misfire monitor
Fuel System Mon --Fuel System Monitor
Comp. Component--Comprehensive Components Monitor
EGR--EGR System Monitor
Oxygen Sens Mon--O2 Sensors Monitor
Catalyst Mon--Catalyst Monitor
EVAP System Mon--Evaporative System Monitor
Oxygen Sens Htr--O2 Sensor Heater Monitor
Sec Air System-- Secondary Air Monitor
HTD--Heated Catalyst Monitor
A/C Refrig Mon--A/C System Monitor
