20
Since DTCs Cleared
MIL Status OFF
Misfire Monitor OK
Fuel System Mon. OK
Comp. Component OK
5) If the vehicle supports readiness test of “This Drive Cycle”, a
screen of the following will be displayed:
This Drive Cycle
MIL Status ON
Misfire Monitor OK
Fuel System Mon. OK
Comp. Component OK
The number “x/x” to the upper right-hand corner of the screen
indicates the total number of screens the retrieved data cover and
sequence of currently displayed data.
6) Press ENTER/EXIT button to return to the previous menu.
4.7 Viewing the VIN Number
The ‘Vehicle Info’ function allows retrieval of the Vehicle Identification
No. (VIN), Calibration ID Nos, (CINs), Calibration Verification Nos
(CVNs) and in-use Performance Tracking on y2000 and newer vehicles
that support Mode 9.
1) Use the SCROLL button to select Vehicle Info from the Diagnostic
Menu and press the ENTER/EXIT button.
Diagnostic Menu
5) View Freeze Frame
6) I/M Readiness
7) Vehicle Info
8) Exit
2) Wait a few seconds or press ENTER/EXIT button to continue.
Vehicle Info
Turn Key On
With engine off!
Press (Enter) to con.
If the vehicle does not support this mode, a “The selected mode is
not supported!” message shows on the display.
