ELECTRICAL CONNECTIONS
Connect the mains lead to a standard 230 Volt (50Hz) electrical supply through an
approved BS1363, 13amp plug or a suitably fused isolator switch.
We recommend that the compressor is connected to the mains supply through a
Residual Current Device (RCD).
WARNING! THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in the mains lead are coloured in accordance with the
following code:
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible cord of this appliance may not correspond with the
coloured markings identifying terminals in your plug proceed as follows:
• Connect GREEN & YELLOW cord to terminal marked with a letter “E” or Earth
symbol “ ” or coloured GREEN or GREEN & YELLOW.
• Connect BROWN cord to terminal marked with a letter ‘L’ or coloured RED
• Connect BLUE cord to terminal marked with a letter ’N’ or coloured BLACK
If this appliance is fitted with a plug which is moulded onto the electric cable (i.e.
non- rewirable) please note:
1. The plug must be thrown away if cut from the electric cable. There is a danger
of electric shock if it is subsequently inserted into a socket.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the correct
replacement is used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer or most
electrical stockists.
5. The fuse in the plug must be replaced with one of the same rating (13amps)
and this replacement must be ASTA approved to BS1362.
If in doubt, consult a qualified electrician....DO NOT attempt repairs yourself
Fuse Replacement
The fuse in the plug must ASTA approved to BS1362and rated at 13 amps
- 5 -
-12 -
Should you experience any difficulties obtaining accessories, please contact the
Clarke sales department (telephone 01992 565300) for details of your nearest
dealer.
ACCESSORIES
Your Jumbo Air Compressor can be used in conjunction with a range of optional
accessories for inflating tyres, air brushing, stapling, blowing and many other uses.
For details contact your local accessory stockist. A complete kit is available from
your Clarke dealer which is ideal for almost all applications (see below), or the
tools may be purchased separately.
Please quote part number 3110150
For Spare Parts and Service, please contact your nearest dealer,
or CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
