ENGLISH INSTRUCTIONS FOR USE
8 MA10 12E - 107408647
11/2015
TECHNICAL DATA
Model Clarke MA10 12E
Solution tank capacity 0.8 US gal (3 L)
Recovery tank capacity 1.0 US gal (4 L)
Machine size (length x width x height) 15.7 x 14.2 45.3 in (400 x 360 x 1,150 mm)
Cleaning width 12.5 in (310 mm)
Brush diameter 2.6 in (66 mm)
Solution ow 0.05 US gal/min (0.2 L/min)
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 72 dB(A) ± 2 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 83 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 98.4 in/s
2
(< 2.5 m/s
2
)
Maximum gradient when working 2 %
Protection class (electric) Grounded
Vacuum system capacity 0.512 psi (360 mm H
2
O)
Brush rotation speed 2,100 rpm
Total absorbed power 1 hp (0.73 kW)
Electrical system voltage 110-120 V - 50-60 Hz
Weight with empty tanks 26.4 lb (12 kg)
Gross vehicle weight (GVW) 33.0 lb (15 kg)
Shipping weight 35.3 lb (16 kg)
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specic use:
107411860 Brush cyl 310 mm (12.5”) Medium PPL (white)
107411861 Brush cyl 310 mm (12.5”) Hard PPL (black)
107411862 Brush cyl 310 mm (12.5”) Microbre
107411863 Brush cyl 310 mm (12.5”) Carpet
107411864 Manual suction hose kit
107411865 Carpet complete kit
107411866 Two hands working handle kit
107414568 Net kit
107411867 Squeegee 321 mm (13”) kit
107411868 Squeegee 321 mm (13”) carpet kit
For further information concerning the optional accessories, contact an authorised Retailer.
