CA60 20B/CA60 24B
CA60 20D/CA60 20TD
SERVICE MANUAL
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read this book prior
to
operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or
to other personnel; damage to the machine or to other property could occur as well. You must have training in the
operation of this machine before using it. If your operator(s) cannot read this manual, have it explained fully
before
attempting to operate this machine.
All directions given in this book are as seen from the operator’s position at the rear of the machine.
