Clarke CA60 24B - Battery Charger

Service Manual-CA60 24-Electrical System 3
5
Component LocationsBattery Charger (CH1)
 Batteries(BAT1)
 4-way signal connection(J1)
 Battery Connector(C1)
 Brush Circuit Breaker(F1)
 Vacuum Circuit Breaker(F2)
 Traction Circuit Breaker(F3) (only for CA60
20B/24B/20TD)
Batteries (BAT1)
Battery Connector (C1)
Battery Charger(CH1)
4-way signal connection(J1)
Vacuum Circuit Breaker (F2)
Traction Circuit Breaker(F3)
Brush Circuit Breaker (F1)
Figure 3
Figure 4
