Service Manual-CA60 40 Recovery System 83
Component Locations
• Vacuum motor(M2)
• Squeegee vacuum hose
• Recovery water drain hose
• Vacuum relay (K2)
• Vacuum Circuit Breaker 30A (F2)
Vacuum motor(M2)
Squeegee vacuum
hose
Recovery water drain
hose
Vacuum relay (K2)
Vacuum circuit breaker
30A(F2)
Figure 2
Figure 3
