PARTS LIST
11/2015 107408647 - MA10 12E 29
NOZZLE HEAD
KIT ITEM REF. NO. QTY DESCRIPTION
1 107413503 1 KEY LOCK BRUSH JET BLACK
2 107413471 1 AXLE HIGHT ADJUSTMENT ROLLER
3 107413495 1 BRUSH MOUNTING
4 107413493 2 DOSING BRIDGE
5 107411867 1 SQUEEGEE 321MM 13 KIT
5 107411868 1 SQUEEGEE 321MM 13 CARPET KIT
K1 6 1 NOZZLE HEAD CHASSIS
7 107413522 1 SQUEEGEE PEDAL JET BLACK
8 107413487 1 CLUTCH OVERLOAD CPL
9 107413515 1 REAR WHEEL Ø90 WITH AXLE CPL.
K2 10 1 TOP COVER CHASSIS ALTO BLUE
11 107413520 1 SQUEEGEE LIFTER
12 107411860 1 BRUSH CYL 310MM 12.5 MEDIUM PPL WHITE
12 107411861 1 BRUSH CYL 310MM 12.5 HARD PPL BLACK
12 107411862 1 BRUSH CYL 310MM 12.5 MICROFIBRE
12 107411863 1 BRUSH CYL 310MM 12.5 CARPET
K2 13 1 Y-CONNECTOR FOR Ø6/Ø10 TUBE
14 107414818 1 BEARING COVER LEFT JET BLACK
15 107413476 1 BRUSH BEARING COVER
K1 16 2 AXLE FOR SUPPORT ROLLER
17 107413477 1 BANDO BELT (BRUSH)
K1 18 1 FRAME FOR CHASSIS
19 107413478 1 HOSE AIRCHANNEL
20 107413512 1 PARKING PEDAL ORANGE
21 107413521 4 SQUEEGEE LIFTER, BODY
K1 22 2 SUPPORT ROLLOR
K2 23 1 SILICONE HOSE 10X6
K2 24 1 SILICONE HOSE 10X6
K1 25 1 BUMPER RIGHT
K1 26 1 BUMPER, LEFT
27 107413488 1 COVER FOR SQUEEGEE CHANNEL JET BLACK
[K1] 107413509 1 NOZZLE HEAD
[K2] 107413526 1 TOP COVER CHASSIS ALTO BLUE
