PARTS LIST
11/2015 107408647 - MA10 12E 31
BODY COMPLETE
KIT ITEM REF. NO. QTY DESCRIPTION
1 107413535 1 COG WHEEL M3 14 T
2 107414820 2 SEALING F. PROFILE, LEFT RIGHT
3 107414814 1 WIRE W. FASTONS
4 107414816 2 PROFIL ALUMINIUM WITH TUBES
5 107413523 1 SILICONE HOSE 10X6
6 107413505 1 LID FOR FILTER JET BLACK
K1 7 1 P-CLIP
8 107416434 1 MOTOR HOUSING US
9 107413499 1 GASKET IN/OUT
K3 10 1 FLOW BASE JET BLACK
11 107416429 1 DOSING PUMP, CLARKE
K2 12 1 LID FOR OUTLET, MOTOR
K1 13 1 LID FOR OUTLET, TURBINE
K3 14 1 ADAPTER TOP COVER
15 107413496 1 FILTER
16 107414822 1 TOP COVER BASE JET BLACK
17 107413497 1 SOLUTION FILTER
K2 18 1 BODY LEFT JET BLACK
19 107413508 1 M5X10 BOLT
K3 20 1 TOPCOVER, ALTO SCRUBTEC 130
21 107413486 1 CAP FOR SPOT CLEANING BLACK
K3 22 1 ADAPTER TUBE 90°
K2 23 1 POM BEARING LEFT
K1 24 1 POM BEARING RIGHT
K1 25 1 BODY RIGHT JET BLACK
26 107413529 1 T-NUT, M5
K2 27 107413479 1 BEND FOR SUCTION HOSE
[K1] 107416425 1 BODY RIGHT RAL 7016
[K2] 107416426 1 BODY LEFT RAL 7016
[K3] 107416437 1 TOP COVER CLARKE
