PARTS LIST
11/2015 107408647 - MA10 12E 37
HANDLE COMPLETE
KIT ITEM REF. NO. QTY DESCRIPTION
1 107413470 1 2-HAND HANDLE
2 107416436 1 USER INTERFACE COVER, CLARKE
3 107413482 1 CABLE F. 2 SWITCH UI
4 107413480 1 CARABINA AND SPRING FOR HANDLE
5 107413489 1 DETACHABLE CORD MALE PLUG
6 107413472 1 ALUMINUM TUBE (HANDRAIL)
7 107416432 1 HANDLE SCRUBBER CLARKE
8 107413516 1 SWITCH, MAIN
9 107413517 1 SWITCH F. PUMP
107408647(1)11-2015 A.indb 37 25/11/2015 09:22:52
