28
COMPONENT PARTS - HEAD ASSEMBLY
No. Description Part No.
1 Belt Tension Locking Screw DD1610205
2 Screw Set M10 4030430
3 Belt Tension Lever DD16102004
4 Stop Pin DD16104010
5 Depth Stop Collar w/Scale DD16104003
6 Depth Locking Screw DD16104012
7 Spindle Feed Shaft DD16104000
8 Scale Guide DD16104004
9 Knob DD16104011
10 Feed handle DD16104005
11 Lockwasher DDGB8621-87
12 Pan Head Screw M5 3040485
13 Switch Box DD16102008A
14 ON/OFF switch Assembly DDKJD12A
15 Pan Head Screw DDGB845-85
16 Light Switch DDRF1001
17 Lead DD16102018A
18 Special SL Screw DD16102021
19 Hrex. Nut M10 3040602
20 Quill Spring Seat DD16104006
21 Quill Spring Retainer DD16104007
22 Quill Spring DD16104009
23 Spring Cap DD16104008
24 Hex. Nut DDGB6172-86
25 Head w/Pointer and Trim DD16102001
26 Bulb Socket DD16202013B
27 Hex. Wrench 5mm DDGB5356-86
28 Hex. Wrench 3mm DDGB5356-86
29 Cable Tie DD16102017
30 Power Cable w/Plug DD16102015I
31 Connector Wire DD16102019
32 Pan Head Screw M6 3040420
33 Cable Clamp DD16102014
34 Pan Head Screw M5 3040656
35 Motor Suppprt Bracket DD16102002
36 Hex. Head Screw M8 3040502
37 Washer DDGB792-85
38 Motor Mount DD16102007A
39 Motor Cable DD16102016B
40 Hex. Nut M8 3040601
41 Motor Assembly DDYL7124-03
42 Hex. Nut M12 3040603
43 Lock Washer DDGB93-87
44 Motor Support Bracket DD16102002
45 Hex. Head Screw M8 3044500
46 Adjusting Lever DD16102006
47 Lead DD16102029
