30
COMPONENT PARTS - BELT DRIVE
No.Description Part No
1 Circlip DD16102024
2 Bearing 60204 BRG60204
3 Bearing Spacer DD16102023
4 ‘V’ Belt A27 DD16201511
5 Pulley Nut DD16102025
6 Pulley Spindle DD16105009B
7 Pulley Insert DD16102022
8 Pulley Cover w/Labels DD16105000
9 Rd Head Screw M6 3040650
10 Set Screw M8 3040528
No.Description Part No.
11 Motor Pulley DD16205005
12 Knob DD16105008
13 Pan Head Screw M5 3040656
14 Idler Pivot DD16205007
15 Idler Pulley DD16205006
16 Bearing 60202 BRG60202
18 Foam Washer DD13105009
19 Microswitch DDXN5
20 Microswitch Cover See dealer
