4
ENGLISH
2. Buttons and Functions
2.1 The record player
1. Lid/dust cover
.
Functions indicator
3. IR sensor for remote control
4.
SD card connection
5. USB connection
6. AUX-IN – Input for external audio source
(3.5 mm stereo)
7. Display
8.
● REC – Records to
USB memory/memory card
9.
I◄◄ – Previous track
18. Adaptor
19. Light
0. Balance weight
– for adjusting pickup pressure
1. ANTI-SKATING – Skating compensator
10.►►I – Next track
11.►II / ■ – Play/Pause/Stop
1. EJECT – Returns tone arm
13. Function switch
(STANDBY/PHONO/USB/SD/AUX-IN)
14. SOURCE – Selects USB memory or SD card
15. FOLDER UP – Switchs folder (during MP3 playing)
16. REPEAT/INTRO/RAN – Repeated/Intro/
Random playback
17. PROG – Programmed playback
(during MP3 playback)
. Tonearm lever
3. Tonearm lock
4. Speed control 33/45 rpm
5. Pitch control – Fine tune speed control setting
134
5 6 7
8 9 10 11
121317
2
16 15 14
20
18
19
21
22
23
24
25
28
