15
played.( if AUX OUT and OUTPUT interface of MIDI keyboard is connected with AUX IN interface of
electron piano by using the big junction board, and make the speaker of digital piano sound together. )
●To change the timbre of digital piano, timbre of connected equipments will be changed(when the power is
on, process transmits sender and receiver signal, refer to 20 pages )
2. Using order control unit to play and record.
Digital piano is connected with MIDI interface of order controller by two cables as per drawing
separately. Order controller is set to record, at this time, play electron piano, order controller can record the
play content. Also record again and play automatically.
● Normally, unit, witch can record the MIDI play content, is called order controller. 2 MIDI interfaces is
installed in the back board (input, output)
3. MIDI IN (input) it is a terminal that receives the data from other unit.
4. MIDI OUT (output) transmits data of digital piano to terminal of other units. Use special MIDI cable
that is sold in the market.
Connection method of cable as per the following drawing, from MIDI IN connection to other units MIDI
IN. plug is being inserted, please pay attention to direction and jack, put it into vertically.
Set MIDI.
Basic operation and button of MIDI operation.
General operation
Press the button of tonal modification or MIDI, and press the appointed, that means, it is going to setting
status is needed. On the condition, setting is made, setting is stopped, that means, the status is removed.
1. set track
MIDI is connected with cable, play signals are transmitted to instruments, and instruments are played at
the same time. Play signals are the same as TV; it is corresponding to different tracks. There are 1-16
tracks. If one play data is received, it should select to change track (receive track). When digital piano is
connected with many units, only unit that is on the same track can transmit data. Unit that transmits data
should have the same track with the digital piano (send track)
A. Set sending track
Holding press MIDI button and press the keyboard’s key (C2 and D3#), select transmit track.sending
track will be changed in 1-16.
B. Set receiving track.
