Clayton CF700M - Page 28

28
PART ITEM
8675710
88212
7
882141
882134
882109
890665
265963
8914142
8387411
2694512
405618
241036
273121
9
4
5
7
10
11
8
3
2
6
12
1
Key Part No. Description Qty
1 27312 Side Panel 2
2 891414 Half Firebrick 1
3 26596 Firebrick Notched (4-1/2 X 9) 2
4 88213 Side Blanket 2
5 89066 Firebrick (4-1/2 X 9) 34
6 24103 Firebrick, Half (4-1/2 X 4-1/2) 1
7 88212 Base Blanket 1
8 40561 Ash Plug 1
9 88210 Bafe Board 2
10 86757 Tube, Air Secondary 4
11 83874 1/8 Dia. X 1-1/2 Cotter Pin 4
12 26945 Brick Retainer 1
Replacement Parts
In order to maintain warranty, components must be replaced using original manufacturers parts purchased
through your dealer or directly from the appliance manufacturer. Use of third party components will void
the warranty.
