29
1
2
4
5
6
9
8
7
10
11
3
Key Part No. Description Qty
1 68234 Assy, Blower/T’stat Brkt. 1
2 68231-1 Fan Cntrl Cord Assy 1
3 80131 4 X 4 Junction Box 1
4 80232 Supply Cord 1
5 68231-2 Fan Cntrl Cord Assy 1
6 80230 Blower Assembly 2
7 89319 Blower Gasket 2
8 68231-3 Fan Cntrl Cord Assy 1
9 22140 Control Mounting Bracket 1
10 80314 F120 Thermodisc 1
11 80231 Cover, Junction Box 1
In order to maintain warranty, components must be replaced using original manufacturers parts purchased
through your dealer or directly from the appliance manufacturer. Use of third party components will void
the warranty.
Replacement Parts
