7. Technical data
concept active turntable
Construction details: Resonance-optimised bodywork; body comprises medium-
density wood bre or pressure-formed solid wood; upper layer
incorporates high-tech satined plastic compound.
Speed change: Electronic speed selection, 33 1/3rpm, 45rpm, 78rpm (optional)
Drive unit: Decoupled and resonance damped DC motor, at belt-drive and
plug-in power supply unit designed for worldwide use with all
networks and power frequencies.
Bearing: Polished and tempered steel shaft in a sintered bronze housing,
running on a Teon thrust-pad.
Platter: Synthetic material, CNC precision milled surface; 30mm / 1.18
inch thickness; aluminium sub-platter
Speed accuracy
(measured):
± 0.05%
Power consumption: Max. consumption: 17 watts / O mode: 0.0 watts
Amplication of the
integrated phono preamp
@ 0.5mV by 1kHz:
low 40db; mid 54dB; high 60dB (Gain setting)
(MM / MC mode)
THD of the integrated
phono preamp:
< 1% @ 400mV output (MM / MC mode)
S/N of integrated phon
preamp:
-84dB (MM mode) / -74dB (MC mode)
RIAA accuracy of
integrated phono preamp:
± 0.5dB
Input load of integrated
phono preamp:
47 kOhm (MM mode) / 110 Ohm (MC mode)
Max. output voltage of
integrated phono preamp:
< 10V
Total weight: Approx. 7.6kg /
wood/dark wood approx. 8.0kg (incl. tonearm and cartridge)
Dimensions (W/D/H): Approx. 16.54 x 13.78 x 4.92 inches (with tonearm)
Warranty: 3 years*
* Provided that the warranty card is correctly completed and returned to Clearaudio, or your product is registered online at
https://clearaudio.de/en/service/registration.php, within 14 days of purchase.
