User manual / Bedienungsanleitung
Page / Seite 5 clearaudio electronic GmbH 2015
2. Satisfy – tonearm mounting
To mount the tonearm base on your armboard, please use the delivered screws (M4 x 10),
as you can see in Pic.1.
Picture 1: Mount tonearm base
Please put careful the cables and the tonearm through the armboard, pay attention that no
wire will be damaged! Now fix the tonearm with the 2 screws on the right and the left side,
not to much, so that you can adjust it in the next steps!
Picture 2: Putting the tonearm through the armboard
