750-297
Profire E/LNE Series Manual
2-1
CHAPTER 2 Installation
2.1 — Application
Electrical power available is usually 208 volt, 3-phase, 60 cycle, 230/460 volt, 3-phase, 60 cycle or 380 volt,
3-phase, 50 cycle. Control circuit is 115 volt, single phase, 60 cycle or 115 volt, single phase, 50 cycle. Refer
to the electrical schematic diagram shipped with the burner. Power connections are made at the control panel.
Wiring from the panel to burner mounted components is installed at the factory. Wiring from the burner panel to
boiler controls, low water controls, remote compressor motor, and remotely located fuel valves is furnished by the
installer.
2.2 — Draft Conditions
Automatic over-fire draft control or barometric draft regulators are not usually required except where the system
has a tall chimney. The exact height of a chimney requiring draft control is indeterminate, but draft regulation is
seldom needed for chimneys less than 50 feet high, especially with Scotch Marine or sealed firebox boilers.
