Cleaver-Brooks Profire E Series - Page 5

Standard Specifications for EG-EL-ELG Series: Gas, #2 Oil, Gas/Oil Configuration
Burner
Model
Gas Input
MBtu/hr
#2 Oil
Input
US GPH
BHP
@80%
Eff.
Furnace
Pressure
(“W.C.)
Blower
Motor
HP
Separate
Comp.
Module
Motor HP
3 PH
Metering
System
Motor HP
3 PH.
Blower Motor
Volt/PH 60 Hz.
E-84-1 8,400 60 200 4 3 3 1/2 208/230/460/3/60
E-105-1 10,500 75 250 4 5 3 1/2 208/230/460/3/60
E-126-1 12,600 90 300 4 5 3 1/2 208/230/460/3/60
E-147-1 14,700 105 350 4 7 1/2 5 1/2 208/230/460/3/60
E-168-2 16,800 120 400 4 10 5 1/2 208/230/460/3/60
E-210-2 21,000 150 500 4 15 5 3/4 208/230/460/3/60
E-252-2 25,200 180 600 4 15 7 1/2 3/4 230/460/3/60
E-294-3 29,400 210 700 4 20 7 1/2 3/4 230/460/3/60
E-336-3 33,600 240 800 4 20 7 1/2 3/4 460/3
E-378-3 37,800 270 900 4 25 15 1 460/3
E-420-3 42,000 300 1,000 4 30 15 1 460/3
Standard Specifications for EG-EL-ELG Series:
Gas, #2 Oil, Gas/Oil Configuration
Burner
Model
Standard Gas
Train Pipe Size
(in.)
Gas
Pressure
Required
(PSI)
E-84-1 2 1/2 2.1
E-105-1 3 2.2
E-126-1 3 2.5
E-147-1 3 2.7
E-168-2 3 3.0
E-210-2 3 3.9
E-252-2 3 4.3
E-294-3 3 2.6
E-336-3 3 3.1
E-378-3 4 3.6
E-420-3 4 3.7
NOTES:
Input is based on fuel BTU content, listed furnace pressure
and altitude of 2,000 feet or less. If altitude >2,000 feet and
<8,000 feet, derate capacity 4% per 1,000 feet over 2,000.
Consult factory for higher altitudes. If furnace pressure
exceeds listed value, derate capacity 5% for every 0.5 “w.c.
of pressure in excess of stated. Consult factory if derate
exceeds 20%. Gas input is based on natural gas with 1,000
BTU/cu. ft., 0.60 gravity, 0 furnace pressure and the
aforementioned conditions. For total pressure at manifold,
add furnace pressure. Oil input based on 140,000 BTU/gal.
and the aforementioned conditions. Consult factory for 50
Hz. applications.
