Accessories
7-4
750-297
Profire E/LNE Series Manual
FIGURE 7-4. Plant Air System/Top Loaded with Oil
WIRE TO FLAME
SAFEGUARD BLOWER
MOTOR TERMINAL
FROM
AIR
SUPPLY
AIR
FLOW
OIL PRESSURE DOWN STREAM
OF OIL METERING VALVE/NOZZLE
PRESSURE TO TOP LOAD AIR
PRESSURE REGULATING VALVE
NOTE:
1 - AIR PRESSURE REGULATOR SHOULD HAVE TRIM KIT
TO ALLOW OIL OVER REGULATOR
